CHIEF HPU

The CHIEF HPU remote model 251319 uses a 3-wire configuration, while the 251317 uses a 4-wire configuration. The 3-wire setup typically connects to a common ground, a power line, and a signal line for controlling one function (e.g., raise/lower). The 4-wire setup adds an additional signal line, allowing control of two independent functions or providing a separate feedback circuit. When selecting a model, verify the wiring diagram of your hydraulic power unit to ensure compatibility. Both models operate at 12V DC and feature two buttons.

CHIEF HPU remote controls are designed for 12V DC hydraulic power units and can be used with non-CHIEF units if the electrical interface matches. The key compatibility factors are the number of wires (3 or 4), the voltage (12V DC), and the button function logic (momentary or maintained contact). You should consult the wiring schematic of your HPU to confirm that the remote's wire colors and signal assignments align. If the HPU uses a different connector or pinout, you may need to adapt the wiring. 3G Electric recommends verifying specifications before purchase.

CHIEF HPU remote handsets are available with cable lengths of 10 feet and 20 feet. For example, model 251319 (3-wire) and 251317 (4-wire) come with a 10-foot cable, while model 251200 (3-wire) has a 20-foot cable. The cable length affects the operator's working distance from the hydraulic power unit. Choose a longer cable for applications requiring greater mobility or when the HPU is positioned far from the control point. All cables are factory-attached and rated for industrial use.

CHIEF HPU remote controls are constructed for industrial environments but do not carry a published IP rating across all models. The handsets are typically built with sealed enclosures to resist dust and moisture ingress, but they are not submersible. For outdoor use in wet or dusty conditions, you should protect the remote from direct exposure or consider additional enclosures. The cable connections are strain-relieved to prevent water entry at the handset. Always check the specific model's datasheet for environmental limits.

The choice between a 3-wire and 4-wire CHIEF HPU remote depends on your hydraulic power unit's control circuit. A 3-wire remote is suitable for systems that control a single bidirectional function (e.g., extend/retract a cylinder) using two buttons. A 4-wire remote is used when the HPU requires separate control for two independent functions or when a feedback signal is needed. Consult your HPU's wiring diagram or controller manual. If the HPU has a terminal block with four connections for the remote, a 4-wire model is likely required.

The lifespan of a CHIEF HPU remote control handset depends on usage frequency, environmental conditions, and cable handling. The switches are rated for mechanical cycles typical of industrial controls (often 100,000 cycles or more). The cable is the most vulnerable component; repeated flexing or sharp bends can cause internal wire breakage. With proper care—avoiding kinking the cable and storing the handset in a dry place—the remote can last several years in regular service. Replacement is straightforward when wear occurs.
