WIDIA CBN POSITIVE

WIDIA is a brand of cutting tools and tooling systems with a history that traces back to the early 20th century, when it was founded as a manufacturer of carbide cutting tools. Over the decades, the brand has expanded its portfolio to include a range of materials and geometries for metal cutting, including cubic boron nitride (CBN) inserts for hard turning applications. The WIDIA CBN POSITIVE line consists of indexable turning inserts with positive rake geometry, designed for precision machining of hardened steels and superalloys. These inserts are available in diamond (C), triangle (T), and other standard ISO shapes, with a variety of sizes and corner radii to suit different turning operations. The positive rake design reduces cutting forces, which can be beneficial for finishing operations where surface finish and dimensional accuracy are critical. The CBN material provides high wear resistance and thermal stability, making it suitable for machining materials that are difficult to cut with conventional carbide tools. 3G Electric supplies the WIDIA CBN POSITIVE line as part of its industrial equipment distribution portfolio. The product range includes multiple SKUs, each corresponding to specific insert geometries and grades. For example, the CCGW and DCGW inserts are available in various sizes, such as CCGW3252S0415M and DCGW11T304S01015MT, with manufacturer part numbers for precise identification. These inserts are typically used in CNC lathes and turning centers for applications requiring tight tolerances and good surface quality. The positive geometry is particularly useful in operations where the workpiece is prone to deflection or where the machine tool has limited rigidity. 3G Electric supports the WIDIA CBN POSITIVE line by maintaining inventory of multiple SKUs and providing logistics support for global delivery. The company serves plant engineers, maintenance managers, and procurement specialists who require specific insert geometries and grades for their machining processes. Technical documentation, including specifications and part numbers, is available to assist in selecting the appropriate insert for a given application. The inserts are packaged and shipped according to standard industrial practices, ensuring that they arrive in condition suitable for use. 3G Electric does not manufacture these products; it distributes them as part of its broader offering of industrial equipment and components. The WIDIA CBN POSITIVE inserts are one of several cutting tool lines available, and they are supplied to customers in various industries, including automotive, aerospace, and general machining. The focus is on providing access to these specialized inserts with efficient order fulfillment and support. For procurement, the key considerations are the insert shape, size, corner radius, and grade, which determine its suitability for specific turning operations. The WIDIA CBN POSITIVE line offers a range of options to address different machining conditions, from light finishing to medium turning. 3G Electric can provide quotes and availability information for the SKUs listed, along with logistics coordination for international shipments. The company's role is to facilitate the acquisition of these products, ensuring that customers receive the correct items in a timely manner. This includes handling customs and shipping documentation as required. The WIDIA CBN POSITIVE inserts are part of a larger ecosystem of tooling solutions, and 3G Electric aims to be a single source for various industrial needs. By stocking multiple SKUs, 3G Electric reduces the need for customers to manage multiple suppliers for different insert types. The product summaries and specifications provided are based on manufacturer data and are intended to help buyers make informed decisions. Overall, the WIDIA CBN POSITIVE line represents a category of high-performance cutting tools for hard turning, and 3G Electric distributes these products to a global customer base.

Genuine
OEM Parts
Expert
Tech Support
1 Day
Quote Response
Worldwide
Origin
EXW Singapore
Collect or forward from our office
Datasheets on Request
Technical specs & drawings
1-Day Quote Response
Singapore-based team
Show
Page 1 of 1

About WIDIA CBN POSITIVE

WIDIA is a brand of cutting tools and tooling systems with a history that traces back to the early 20th century, when it was founded as a manufacturer of carbide cutting tools. Over the decades, the brand has expanded its portfolio to include a range of materials and geometries for metal cutting, including cubic boron nitride (CBN) inserts for hard turning applications. The WIDIA CBN POSITIVE line consists of indexable turning inserts with positive rake geometry, designed for precision machining of hardened steels and superalloys. These inserts are available in diamond (C), triangle (T), and other standard ISO shapes, with a variety of sizes and corner radii to suit different turning operations. The positive rake design reduces cutting forces, which can be beneficial for finishing operations where surface finish and dimensional accuracy are critical. The CBN material provides high wear resistance and thermal stability, making it suitable for machining materials that are difficult to cut with conventional carbide tools. 3G Electric supplies the WIDIA CBN POSITIVE line as part of its industrial equipment distribution portfolio. The product range includes multiple SKUs, each corresponding to specific insert geometries and grades. For example, the CCGW and DCGW inserts are available in various sizes, such as CCGW3252S0415M and DCGW11T304S01015MT, with manufacturer part numbers for precise identification. These inserts are typically used in CNC lathes and turning centers for applications requiring tight tolerances and good surface quality. The positive geometry is particularly useful in operations where the workpiece is prone to deflection or where the machine tool has limited rigidity. 3G Electric supports the WIDIA CBN POSITIVE line by maintaining inventory of multiple SKUs and providing logistics support for global delivery. The company serves plant engineers, maintenance managers, and procurement specialists who require specific insert geometries and grades for their machining processes. Technical documentation, including specifications and part numbers, is available to assist in selecting the appropriate insert for a given application. The inserts are packaged and shipped according to standard industrial practices, ensuring that they arrive in condition suitable for use. 3G Electric does not manufacture these products; it distributes them as part of its broader offering of industrial equipment and components. The WIDIA CBN POSITIVE inserts are one of several cutting tool lines available, and they are supplied to customers in various industries, including automotive, aerospace, and general machining. The focus is on providing access to these specialized inserts with efficient order fulfillment and support. For procurement, the key considerations are the insert shape, size, corner radius, and grade, which determine its suitability for specific turning operations. The WIDIA CBN POSITIVE line offers a range of options to address different machining conditions, from light finishing to medium turning. 3G Electric can provide quotes and availability information for the SKUs listed, along with logistics coordination for international shipments. The company's role is to facilitate the acquisition of these products, ensuring that customers receive the correct items in a timely manner. This includes handling customs and shipping documentation as required. The WIDIA CBN POSITIVE inserts are part of a larger ecosystem of tooling solutions, and 3G Electric aims to be a single source for various industrial needs. By stocking multiple SKUs, 3G Electric reduces the need for customers to manage multiple suppliers for different insert types. The product summaries and specifications provided are based on manufacturer data and are intended to help buyers make informed decisions. Overall, the WIDIA CBN POSITIVE line represents a category of high-performance cutting tools for hard turning, and 3G Electric distributes these products to a global customer base.

Common Applications

  • Automotive — Hard turning of transmission shafts and gears using WIDIA CBN POSITIVE CCGW inserts for finishing to tight tolerances.
  • Aerospace — Machining of superalloy components such as turbine disks with DCGW inserts for precision turning and surface integrity.
  • General machining — Finishing of hardened steel molds and dies with TCGW inserts to achieve required surface finish and dimensional accuracy.
  • Bearing manufacturing — Turning of hardened bearing races using DCMW inserts for consistent tool life and surface quality.
  • Hydraulic components — Precision turning of hardened hydraulic cylinders and rods with CCGW inserts to maintain roundness and finish.
  • Tool and die — Refurbishment of hardened tooling with WIDIA CBN POSITIVE inserts for controlled material removal and edge quality.

Guides & Resources

Frequently asked questions

Common questions about WIDIA CBN POSITIVE from 3G Electric.

What is the difference between WIDIA CBN POSITIVE inserts and conventional carbide inserts?

WIDIA CBN POSITIVE inserts are made from cubic boron nitride, a material with higher hardness and thermal stability than tungsten carbide. This makes them suitable for machining hardened steels and superalloys, where carbide inserts may wear rapidly. The positive rake geometry further reduces cutting forces, which can improve surface finish and dimensional control in finishing operations. Carbide inserts are generally used for softer materials or roughing operations where the higher toughness of carbide is beneficial. The choice between CBN and carbide depends on the workpiece material, hardness, and required surface quality.

What are the available geometries for WIDIA CBN POSITIVE inserts?

The WIDIA CBN POSITIVE line includes several ISO-standard insert shapes, such as diamond (C), triangle (T), and others. Specific models include CCGW, DCGW, TCGW, and DCMW, with various sizes and corner radii. For example, CCGW3252S0415M and DCGW11T304S01015MT are common configurations. The part numbers, such as 6904855 for TCGW inserts, help identify the exact geometry and grade. The positive rake is a common feature across the line, designed to reduce cutting forces. The selection depends on the turning operation, workpiece material, and machine tool conditions.

Can WIDIA CBN POSITIVE inserts be used for interrupted cutting?

WIDIA CBN POSITIVE inserts are generally designed for continuous cutting and finishing operations. Interrupted cutting, such as in milling or turning with interruptions, can subject the insert to impact loads that may cause chipping or breakage. The CBN material is hard but relatively brittle compared to carbide. For interrupted cuts, a tougher grade or a different tooling solution may be required. It is recommended to consult the manufacturer's guidelines for specific applications. In general, these inserts are best suited for smooth turning operations on hardened materials where the cutting edge is continuously engaged.

How do I select the correct WIDIA CBN POSITIVE insert for my application?

Selection depends on several factors: the workpiece material and its hardness, the type of turning operation (finishing, medium, or roughing), the machine tool's rigidity and speed capabilities, and the required surface finish and tolerance. The insert shape (e.g., C, D, T) affects the accessibility and strength of the cutting edge. The corner radius influences surface finish and cutting forces. The grade of CBN determines wear resistance and toughness. Manufacturer catalogs and technical guides provide detailed recommendations. 3G Electric can provide part numbers and specifications for the available SKUs to assist in matching the insert to the application.

What is the typical speed and feed for WIDIA CBN POSITIVE inserts?

Cutting parameters for WIDIA CBN POSITIVE inserts vary with the workpiece material, hardness, and operation. As a general guideline, CBN inserts are run at higher cutting speeds than carbide, often in the range of 100 to 300 m/min for hardened steels, depending on the specific grade and conditions. Feed rates are typically moderate to low for finishing, such as 0.05 to 0.2 mm/rev. Depth of cut is usually light, especially for finishing. These are starting points; optimal parameters should be determined through testing or by consulting the manufacturer's recommendations. The positive geometry allows for lower cutting forces, which can permit higher speeds or feeds in some cases.

Are WIDIA CBN POSITIVE inserts available in different grades?

The WIDIA CBN POSITIVE line includes inserts with different CBN grades, which are indicated by the suffix in the part number, such as S0415M or S01015MT. These grades may differ in CBN content, binder material, and coating, affecting properties like wear resistance, toughness, and thermal stability. The specific grade should be selected based on the workpiece material and cutting conditions. For example, a grade with higher CBN content may offer better wear resistance for high-speed finishing, while a grade with a ceramic binder may provide improved toughness. The manufacturer's technical data provides guidance on grade selection for various applications.
