3M Splice Kit: 1,000 V Max Volt - Molded Resin Splice Kits
3MMolded Resin Splice Kits

3M Splice Kit: 1,000 V Max Volt

The 3M Splice Kit (MPN 85-16) is a molded resin splice kit for 1,000 V max volt applications, accommodating a 4/0 AWG to 250 kcmil wire size range. The kit includes a plastic mold and a closed mixing pouch, featuring…

SKU 3G-OTH-21062

Brand
3M
Item
Splice Kit: 1,000 V Max Volt
Category
Molded Resin Splice Kits
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

3M
Manufacturer Part Number
85-16
Kit Includes
Plastic Mold
Container Type
Closed Mixing Pouch
Special Features
Pressure-Sensitive Adhesive Film Sealing Strip
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

3M Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The 3M Splice Kit (MPN 85-16) is a molded resin splice kit for 1,000 V max volt applications, accommodating a 4/0 AWG to 250 kcmil wire size range. The kit includes a plastic mold and a closed mixing pouch, featuring a pressure-sensitive adhesive film sealing strip.

Frequently Asked Questions

What is the 3M Splice Kit 85-16 used for?

The 3M Splice Kit 85-16 is used for splicing and insulating electrical cables rated up to 1,000 V max volt. It accommodates wire sizes from 4/0 AWG to 250 kcmil, making it suitable for industrial power distribution, motor connections, and junction box installations where a molded resin splice is required.

What are the specifications of the 3M Splice Kit 85-16?

The 3M Splice Kit 85-16 has a maximum voltage rating of 1,000 V and a wire size range of 4/0 AWG to 250 kcmil. It includes a plastic mold and a closed mixing pouch. A pressure-sensitive adhesive film sealing strip ensures a secure seal. The manufacturer part number is 85-16.

Where to buy the 3M Splice Kit 85-16 worldwide?

You can source the 3M Splice Kit 85-16 worldwide through 3G Electric. As a global industrial equipment distributor, 3G Electric handles full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this molded resin splice kit.

How to install the 3M Splice Kit 85-16?

To install the 3M Splice Kit 85-16, strip cable insulation to the recommended length, insert conductors into the plastic mold, and mix the resin in the closed mixing pouch. Pour the resin into the mold, then seal with the pressure-sensitive adhesive film strip. Allow curing per 3M's instructions before energizing.
