AEROQUIP Hydraulic Crimp Fitting: Steel x Steel, Straight, -24 For Hose Dash Size - Crimp Hydraulic Hose Fittings with Flange Connection
AEROQUIPCrimp Hydraulic Hose Fittings with Flange Connection

AEROQUIP Hydraulic Crimp Fitting: Steel x Steel, Straight, -24 For Hose Dash Size

The AEROQUIP Hydraulic Crimp Fitting (MPN 4S24FL24) is a steel x steel straight crimp hose fitting with a flange x crimp connection type, designed for hose dash size -24. It features a male x genderless fitting…

SKU 3G-OTH-470877

Brand
AEROQUIP
Item
Hydraulic Crimp Fitting: Steel x Steel, Straight, -24 For Hose Dash Size
Category
Crimp Hydraulic Hose Fittings with Flange Connection
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

AEROQUIP
Manufacturer Part Number
4S24FL24
Type
Straight, -24 For Hose Dash Size, Male x Genderless
Fitting Gender
Male x Genderless
For Hose Dash Size
-24
Fitting Connection Type
Flange x Crimp
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

AEROQUIP Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The AEROQUIP Hydraulic Crimp Fitting (MPN 4S24FL24) is a steel x steel straight crimp hose fitting with a flange x crimp connection type, designed for hose dash size -24. It features a male x genderless fitting gender, enabling versatile coupling in hydraulic systems.

Frequently Asked Questions

What is the AEROQUIP 4S24FL24 hydraulic crimp fitting used for?

The AEROQUIP 4S24FL24 is a steel straight crimp fitting used to connect -24 dash size hydraulic hose to flanged ports. Its male x genderless design enables versatile coupling in high-pressure hydraulic systems across industrial machinery, mobile equipment, and fluid power applications.

What are the specifications of the AEROQUIP 4S24FL24 fitting?

The AEROQUIP 4S24FL24 is a steel x steel straight crimp fitting with a flange x crimp connection type. It fits hose dash size -24, has a male x genderless fitting gender, and carries manufacturer part number 4S24FL24. It is designed for reliable hydraulic system connections.

Where to buy AEROQUIP 4S24FL24 worldwide?

3G Electric supplies the AEROQUIP 4S24FL24 hydraulic crimp fitting to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this genuine AEROQUIP part.

How to install an AEROQUIP flange x crimp fitting?

Installation requires a compatible crimping machine and die set for -24 hose. Ensure the hose end is clean and cut square. Insert the fitting stem into the hose, position the ferrule, and crimp per AEROQUIP specifications. Always verify crimp diameter with a gauge after assembly.

Used in

Common applications for AEROQUIP
Mobile hydraulic equipment repair — Aeroquip 45° elbow flange fittings (e.g., 1A12FLA10) for hose replacement on excavators and loaders.
Industrial hydraulic power units — Aeroquip 90° elbow flange fittings (e.g., 4S20FLB20) for connecting pumps to manifold blocks.
In-house hose assembly shops — Aeroquip die packages (e.g., ET4020TP-0002) for crimping 1-wire braid hoses up to 1 1/4 in diameter.
Oil and gas field equipment — Aeroquip carbon steel flange fittings (e.g., 1A24FLA20) for high-pressure fluid transfer lines.
Hydraulic press maintenance — Aeroquip die cage assemblies (e.g., FT1382-200-M465) for crimping 4-spiral hoses on heavy-duty presses.
Agricultural machinery servicing — Aeroquip 45° elbow fittings (e.g., 1A12FLA12) for replacing hoses on tractors and harvesters.
