AEROQUIPFF Series Hydraulic Quick-Connect Coupling Plugs

AEROQUIP Hydraulic Quick Connect Hose Coupling: 3/8 in, Steel, 37.85 lpm Max. Flow Rate

The AEROQUIP FF Series Hydraulic Quick-Connect Coupling Plug (SKU 55JT16, MPN FD49-1002-06-06) is a push-to-connect coupling with a steel body and 3/8"-18 FNPT threads. It has a maximum flow rate of 37.85 lpm.

SKU 3G-OTH-451750

Brand

AEROQUIP

Item

Hydraulic Quick Connect Hose Coupling: 3/8 in, Steel, 37.85 lpm Max. Flow Rate

Technical Specifications

AEROQUIP

Manufacturer Part Number

FD49-1002-06-06

Type

Steel, 37.85 lpm Max. Flow Rate, FNPT

Thread Size

3/8"-18

Body Material

Steel

Coupling Locking Type

Push-to-Connect

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

AEROQUIP Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

What is the AEROQUIP FD49-1002-06-06 hydraulic quick connect coupling used for?

The AEROQUIP FD49-1002-06-06 is a push-to-connect hydraulic coupling plug used in fluid power systems to quickly connect and disconnect hose lines under pressure. It is commonly applied in mobile equipment, industrial machinery, and hydraulic tools requiring reliable, leak-free connections.

What are the specifications of the AEROQUIP FD49-1002-06-06?

This AEROQUIP FF Series coupling has a steel body, 3/8"-18 FNPT threads, and a push-to-connect locking type. It handles a maximum flow rate of 37.85 lpm. The manufacturer part number is FD49-1002-06-06, and the SKU is 55JT16.

Where to buy the AEROQUIP FD49-1002-06-06 worldwide?

3G Electric supplies the AEROQUIP FD49-1002-06-06 hydraulic coupling to customers worldwide. As a global industrial sourcing partner, we handle logistics, customs clearance, and delivery to your location. Contact us for a quote and lead time on this AEROQUIP part.

How to install the AEROQUIP push-to-connect coupling?

To install the AEROQUIP FD49-1002-06-06, ensure the mating coupler is clean and undamaged. Align the plug with the coupler and push firmly until it locks audibly. Always depressurize the system before connection or disconnection. Use thread sealant on the FNPT ports to prevent leaks.

Used in

Common applications for AEROQUIP

Mobile hydraulic equipment repair — Aeroquip 45° elbow flange fittings (e.g., 1A12FLA10) for hose replacement on excavators and loaders.

Industrial hydraulic power units — Aeroquip 90° elbow flange fittings (e.g., 4S20FLB20) for connecting pumps to manifold blocks.

In-house hose assembly shops — Aeroquip die packages (e.g., ET4020TP-0002) for crimping 1-wire braid hoses up to 1 1/4 in diameter.

Oil and gas field equipment — Aeroquip carbon steel flange fittings (e.g., 1A24FLA20) for high-pressure fluid transfer lines.

Hydraulic press maintenance — Aeroquip die cage assemblies (e.g., FT1382-200-M465) for crimping 4-spiral hoses on heavy-duty presses.

Agricultural machinery servicing — Aeroquip 45° elbow fittings (e.g., 1A12FLA12) for replacing hoses on tractors and harvesters.
