AIGNEP USA Push-Fit Elbow Fitting: 5/16 in OD x 1/8 in Pipe Size - Stainless Steel Tube Fittings
AIGNEP USAStainless Steel Tube Fittings

AIGNEP USA Push-Fit Elbow Fitting: 5/16 in OD x 1/8 in Pipe Size

The AIGNEP USA Push-Fit Elbow Fitting (MPN 60111X-05-02) is a stainless steel tube fitting with a Push-to-Connect x Universal Thread design, sized for 5/16 in OD tubing and a 1/8 in pipe size with a 1/8-27 thread. 3G…

SKU 3G-OTH-480076

Brand
AIGNEP USA
Item
Push-Fit Elbow Fitting: 5/16 in OD x 1/8 in Pipe Size
Category
Stainless Steel Tube Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

AIGNEP USA
Manufacturer Part Number
60111X-05-02
Type
Push-to-Connect x Universal Thread
Thread Size A
1/8-27
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

AIGNEP USA Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The AIGNEP USA Push-Fit Elbow Fitting (MPN 60111X-05-02) is a stainless steel tube fitting with a Push-to-Connect x Universal Thread design, sized for 5/16 in OD tubing and a 1/8 in pipe size with a 1/8-27 thread. 3G Electric interprets your demand for this OEM part, sourcing it across 14 industrial departments—including pneumatics—with specialist depth in combustion, pumps, and controls as an authorized distributor.

Frequently Asked Questions

What is the AIGNEP USA Push-Fit Elbow Fitting used for?

This AIGNEP USA Push-Fit Elbow Fitting (MPN 60111X-05-02) connects 5/16 in OD tubing to a 1/8 in pipe port with a 1/8-27 thread. It is used in pneumatic systems, instrumentation, and fluid handling applications where a compact, leak-resistant stainless steel connection is required.

What are the specifications of the AIGNEP USA 60111X-05-02?

The AIGNEP USA 60111X-05-02 is a Push-to-Connect x Universal Thread elbow fitting. It accepts 5/16 in OD tubing and has a 1/8 in pipe size with a 1/8-27 thread. The fitting is made of stainless steel, offering corrosion resistance for industrial pneumatic and fluid systems.

Where to buy the AIGNEP USA 60111X-05-02 worldwide?

3G Electric supplies the AIGNEP USA 60111X-05-02 Push-Fit Elbow Fitting to customers worldwide. We handle full logistics, customs clearance, and delivery, sourcing this OEM part across 14 industrial departments including pneumatics. Contact us for availability and lead time.

How to install the AIGNEP USA Push-Fit Elbow Fitting?

To install the AIGNEP USA Push-Fit Elbow Fitting, ensure the tubing is cut square and free of burrs. Push the tube fully into the fitting until it stops. For the threaded end, apply thread sealant and tighten to the 1/8-27 port. Always verify the connection is secure before pressurizing the system.

Used in

Common applications for AIGNEP USA
Pneumatic actuator speed control — AIGNEP USA elbow-style speed control valves (e.g., 88973-04-04) regulate cylinder extension and retraction rates.
Compressed air system backflow prevention — AIGNEP USA check valves (e.g., 82663-06) prevent reverse flow in air distribution lines.
Quick exhaust for cylinder retraction — AIGNEP USA quick exhaust valves (e.g., 82650-06) accelerate exhaust air from pneumatic actuators.
Flow regulation in control panels — AIGNEP USA universal flow control valves (e.g., 88953-06-04) adjust air flow in manifold or panel-mounted circuits.
Pneumatic tool supply lines — AIGNEP USA check valves maintain pressure in tool feed lines and prevent backflow during tool changes.
Automated assembly line pneumatic circuits — AIGNEP USA speed control valves (e.g., 88977-04-04) fine-tune motion in pick-and-place or clamping operations.
