AIGNEP USA Push-Fit Wye Fitting: 1/2 in OD x 1/2 in OD Size - Nylon & Nickel-Plated Brass Tube Fittings
AIGNEP USANylon & Nickel-Plated Brass Tube Fittings

AIGNEP USA Push-Fit Wye Fitting: 1/2 in OD x 1/2 in OD Size

The AIGNEP USA Push-Fit Wye Fitting (MPN 85320-08-06) is a nylon and nickel-plated brass tube fitting with a 1/2 in OD x 1/2 in OD size and a Push-to-Connect x Push-to-Connect type. It features a Thread Size A of 3/8-18.

SKU 3G-OTH-492541

Brand
AIGNEP USA
Item
Push-Fit Wye Fitting: 1/2 in OD x 1/2 in OD Size
Category
Nylon & Nickel-Plated Brass Tube Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

AIGNEP USA
Manufacturer Part Number
85320-08-06
Type
Push-to-Connect x Push-to-Connect
Thread Size A
3/8-18
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

AIGNEP USA Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The AIGNEP USA Push-Fit Wye Fitting (MPN 85320-08-06) is a nylon and nickel-plated brass tube fitting with a 1/2 in OD x 1/2 in OD size and a Push-to-Connect x Push-to-Connect type. It features a Thread Size A of 3/8-18.

Frequently Asked Questions

What is the AIGNEP USA Push-Fit Wye Fitting used for?

The AIGNEP USA Push-Fit Wye Fitting (MPN 85320-08-06) is used to split or combine compressed air or fluid flow in pneumatic systems. Its push-to-connect design enables tool-free installation in industrial automation, packaging, and material handling applications across 14 departments.

What are the specifications of the AIGNEP USA Push-Fit Wye Fitting?

This AIGNEP USA fitting has a 1/2 in OD x 1/2 in OD size, Push-to-Connect x Push-to-Connect type, and a Thread Size A of 3/8-18. It is constructed from nylon and nickel-plated brass for corrosion resistance in pneumatic and fluid-handling circuits.

Where to buy the AIGNEP USA Push-Fit Wye Fitting worldwide?

3G Electric supplies the AIGNEP USA Push-Fit Wye Fitting (MPN 85320-08-06) worldwide. We handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this nylon and nickel-plated brass tube fitting.

How to install the AIGNEP USA Push-Fit Wye Fitting?

To install the AIGNEP USA Push-Fit Wye Fitting, cut the tube square, deburr the end, and push it fully into the fitting until it seats. Ensure the collet grips the tube. For threaded connections, use PTFE tape on the 3/8-18 thread and tighten by hand plus 1/4 turn.

Used in

Common applications for AIGNEP USA
Pneumatic actuator speed control — AIGNEP USA elbow-style speed control valves (e.g., 88973-04-04) regulate cylinder extension and retraction rates.
Compressed air system backflow prevention — AIGNEP USA check valves (e.g., 82663-06) prevent reverse flow in air distribution lines.
Quick exhaust for cylinder retraction — AIGNEP USA quick exhaust valves (e.g., 82650-06) accelerate exhaust air from pneumatic actuators.
Flow regulation in control panels — AIGNEP USA universal flow control valves (e.g., 88953-06-04) adjust air flow in manifold or panel-mounted circuits.
Pneumatic tool supply lines — AIGNEP USA check valves maintain pressure in tool feed lines and prevent backflow during tool changes.
Automated assembly line pneumatic circuits — AIGNEP USA speed control valves (e.g., 88977-04-04) fine-tune motion in pick-and-place or clamping operations.
