AIGNEP USA Push-Fit Tee Fitting: 1/4 in OD x 1/4 in OD x 5/16 in Pipe Size, Brass - Nickel-Plated Brass Tube Fittings
AIGNEP USANickel-Plated Brass Tube Fittings

AIGNEP USA Push-Fit Tee Fitting: 1/4 in OD x 1/4 in OD x 5/16 in Pipe Size, Brass

The AIGNEP USA Push-Fit Tee Fitting is a nickel-plated brass tube fitting with a 1/4 in OD x 1/4 in OD x 5/16 in pipe size configuration. It features a #10-32 thread size and is identified by manufacturer part number…

SKU 3G-OTH-482821

Brand
AIGNEP USA
Item
Push-Fit Tee Fitting: 1/4 in OD x 1/4 in OD x 5/16 in Pipe Size, Brass
Category
Nickel-Plated Brass Tube Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

AIGNEP USA
Manufacturer Part Number
88225-04-32
Type
Brass, Silver
Thread Size A
#10-32
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

AIGNEP USA Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The AIGNEP USA Push-Fit Tee Fitting is a nickel-plated brass tube fitting with a 1/4 in OD x 1/4 in OD x 5/16 in pipe size configuration. It features a #10-32 thread size and is identified by manufacturer part number 88225-04-32.

Frequently Asked Questions

What is the AIGNEP USA Push-Fit Tee Fitting used for?

This nickel-plated brass tee fitting is used in pneumatic and fluid-handling systems to split or combine airflow in a 1/4 in OD tube line. It is common in industrial automation, packaging, and assembly equipment where reliable push-fit connections are needed.

What are the specifications of the AIGNEP USA 88225-04-32 fitting?

The AIGNEP USA 88225-04-32 is a nickel-plated brass push-fit tee fitting with three ports: two for 1/4 in OD tubing and one for 5/16 in pipe size. It has a #10-32 thread size and a silver finish. The part is designed for low-pressure pneumatic circuits.

Where to buy AIGNEP USA push-fit fittings in worldwide?

3G Electric supplies AIGNEP USA push-fit fittings like the 88225-04-32 to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this nickel-plated brass tee fitting.

How to install an AIGNEP USA push-fit tee fitting?

To install, cut the tube square and deburr it, then push it fully into the fitting until it stops. The collet grips the tube automatically. For removal, press the collet evenly while pulling the tube out. Ensure the system is depressurized before installation.

Used in

Common applications for AIGNEP USA
Pneumatic actuator speed control — AIGNEP USA elbow-style speed control valves (e.g., 88973-04-04) regulate cylinder extension and retraction rates.
Compressed air system backflow prevention — AIGNEP USA check valves (e.g., 82663-06) prevent reverse flow in air distribution lines.
Quick exhaust for cylinder retraction — AIGNEP USA quick exhaust valves (e.g., 82650-06) accelerate exhaust air from pneumatic actuators.
Flow regulation in control panels — AIGNEP USA universal flow control valves (e.g., 88953-06-04) adjust air flow in manifold or panel-mounted circuits.
Pneumatic tool supply lines — AIGNEP USA check valves maintain pressure in tool feed lines and prevent backflow during tool changes.
Automated assembly line pneumatic circuits — AIGNEP USA speed control valves (e.g., 88977-04-04) fine-tune motion in pick-and-place or clamping operations.
