AMERICAN LOUVER Grille: Louvered Grille, Silver, Mill, Aluminum, 9 1/4 in H, 27 1/8 in W - Surface-Mount Grilles
AMERICAN LOUVERSurface-Mount Grilles

AMERICAN LOUVER Grille: Louvered Grille, Silver, Mill, Aluminum, 9 1/4 in H, 27 1/8 in W

The AMERICAN LOUVER Grille: Louvered Grille is a surface-mount grille designed for exposed duct mounting. This silver, mill-finish aluminum unit measures 9 1/4 inches in height, 27 1/8 inches in width, and 2 inches…

SKU 3G-OTH-78392

Brand
AMERICAN LOUVER
Item
Grille: Louvered Grille, Silver, Mill, Aluminum, 9 1/4 in H, 27 1/8 in W
Category
Surface-Mount Grilles
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

AMERICAN LOUVER
Manufacturer Part Number
SP-24X8-M
Type
Silver, Mill, Aluminum, 27 1/8 in W
D
2 in
H
9 1/4 in
Bar Spacing
3/4 in
Mounting Location
Exposed Duct
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

AMERICAN LOUVER Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The AMERICAN LOUVER Grille: Louvered Grille is a surface-mount grille designed for exposed duct mounting. This silver, mill-finish aluminum unit measures 9 1/4 inches in height, 27 1/8 inches in width, and 2 inches in depth, with a 3/4-inch bar spacing (MPN SP-24X8-M).

Frequently Asked Questions

What is the AMERICAN LOUVER SP-24X8-M louvered grille used for?

The AMERICAN LOUVER SP-24X8-M is a surface-mount louvered grille designed for exposed duct mounting in HVAC systems. It directs airflow while providing a clean, finished appearance in commercial or industrial ventilation applications.

What are the specifications of the AMERICAN LOUVER SP-24X8-M grille?

The AMERICAN LOUVER SP-24X8-M is a silver, mill-finish aluminum louvered grille measuring 9 1/4 inches high, 27 1/8 inches wide, and 2 inches deep, with 3/4-inch bar spacing. It is designed for exposed duct mounting.

Where to buy the AMERICAN LOUVER SP-24X8-M grille worldwide?

3G Electric supplies the AMERICAN LOUVER SP-24X8-M louvered grille worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to install the AMERICAN LOUVER SP-24X8-M surface-mount grille?

Install the AMERICAN LOUVER SP-24X8-M by securing it directly over an exposed duct opening using appropriate fasteners. Ensure the duct opening matches the grille dimensions. Follow standard HVAC grille installation practices for proper airflow and sealing.
