APPLETON ELECTRIC Sealing Fitting - Vertical and Horizontal: Iron, 1/2 in Trade Size, Female - Vertical and Horizontal Sealing Fitting - 25% Fill
APPLETON ELECTRICVertical and Horizontal Sealing Fitting - 25% Fill

APPLETON ELECTRIC Sealing Fitting - Vertical and Horizontal: Iron, 1/2 in Trade Size, Female

The APPLETON ELECTRIC EYS-11 is a vertical and horizontal sealing fitting for 25% fill applications, constructed of iron with 1/2 in FNPT female-to-female threaded ends. It carries a Class III hazardous location…

SKU 3G-OTH-05761

Brand
APPLETON ELECTRIC
Item
Sealing Fitting - Vertical and Horizontal: Iron, 1/2 in Trade Size, Female
Category
Vertical and Horizontal Sealing Fitting - 25% Fill
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPLETON ELECTRIC
Manufacturer Part Number
EYS-11
Material
Iron
Standards
UL 886
Thread Type
NPT
Thread Gender
Female
Threaded Ends
Female to Female
Connection Type
Threaded
Ends - Hazardous Fittings
1/2 in FNPT x 1/2 in FNPT
Hazardous Location Rating
Class III
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPLETON ELECTRIC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPLETON ELECTRIC EYS-11 is a vertical and horizontal sealing fitting for 25% fill applications, constructed of iron with 1/2 in FNPT female-to-female threaded ends. It carries a Class III hazardous location rating and is UL 886 listed.

Frequently Asked Questions

What is the APPLETON ELECTRIC EYS-11 sealing fitting used for?

The APPLETON ELECTRIC EYS-11 is a vertical and horizontal sealing fitting used in Class III hazardous locations to prevent the passage of gases, vapors, or flames through conduit systems. It is designed for 25% fill applications and is UL 886 listed for safety.

What are the specifications of the APPLETON ELECTRIC EYS-11?

The EYS-11 is an iron sealing fitting with 1/2 in FNPT female-to-female threaded ends, NPT thread type, and a Class III hazardous location rating. It meets UL 886 standards and is suitable for vertical and horizontal mounting in 25% fill conduit systems.

Where to buy the APPLETON ELECTRIC EYS-11 worldwide?

You can source the APPLETON ELECTRIC EYS-11 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring compliance with local regulations for hazardous location fittings.

How to install the APPLETON ELECTRIC EYS-11 sealing fitting?

Install the EYS-11 by threading it onto 1/2 in NPT conduit ends, ensuring a tight seal. For Class III locations, follow NEC guidelines for sealing fittings at conduit entries. Use approved sealing compound and allow proper curing time to maintain the hazardous location rating.
