APPLETON ELECTRIC Mechanical Interlock: 600V AC, Single Phase, 30 A, 3 Pole - Hazardous Location Interlocks with Circuit Breakers
APPLETON ELECTRICHazardous Location Interlocks with Circuit Breakers

APPLETON ELECTRIC Mechanical Interlock: 600V AC, Single Phase, 30 A, 3 Pole

The APPLETON ELECTRIC Mechanical Interlock: 600V AC is a Hazardous Location Interlock with Circuit Breakers, designed for Class I environments. This single-phase, 30 A, 3-pole, 2-wire unit features an FD 600V AC…

SKU 3G-OTH-15255

Brand
APPLETON ELECTRIC
Item
Mechanical Interlock: 600V AC, Single Phase, 30 A, 3 Pole
Category
Hazardous Location Interlocks with Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPLETON ELECTRIC
Manufacturer Part Number
EBR3023HFB20
Type
Single Phase, 30 A
Pole
3
Wire
2
Reverse Service
No
Circuit Breaker Type
FD 600V AC
Hazardous Location Class
Class I
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPLETON ELECTRIC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPLETON ELECTRIC Mechanical Interlock: 600V AC is a Hazardous Location Interlock with Circuit Breakers, designed for Class I environments. This single-phase, 30 A, 3-pole, 2-wire unit features an FD 600V AC circuit breaker and operates without reverse service. It is identified by manufacturer part number EBR3023HFB20.

Frequently Asked Questions

What is the APPLETON ELECTRIC Mechanical Interlock EBR3023HFB20 used for?

This hazardous location interlock with circuit breaker is designed for Class I environments, providing safe electrical disconnection in areas with flammable gases or vapors. It is used in industrial plants, refineries, and chemical facilities to control single-phase, 30 A circuits at 600V AC.

What are the specifications of the APPLETON ELECTRIC Mechanical Interlock EBR3023HFB20?

The unit is rated 600V AC, single phase, 30 A, with 3 poles and 2 wires. It includes an FD 600V AC circuit breaker, has no reverse service, and is certified for Class I hazardous locations. The manufacturer part number is EBR3023HFB20.

Where to buy the APPLETON ELECTRIC Mechanical Interlock EBR3023HFB20 worldwide?

3G Electric supplies the APPLETON ELECTRIC Mechanical Interlock EBR3023HFB20 worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to select the correct APPLETON ELECTRIC mechanical interlock for a Class I area?

Verify the hazardous location class (Class I), voltage (600V AC), phase (single), and current rating (30 A). Ensure the circuit breaker type (FD 600V AC) matches your system. The EBR3023HFB20 is a 3-pole, 2-wire unit without reverse service. Consult an engineer for area classification compliance.
