APPLETON ELECTRIC Hazardous Location Circuit Breaker: 3 Poles, 250 A Amps, 600V AC - Hazardous Location Enclosed Circuit Breakers
APPLETON ELECTRICHazardous Location Enclosed Circuit Breakers

APPLETON ELECTRIC Hazardous Location Circuit Breaker: 3 Poles, 250 A Amps, 600V AC

The APPLETON ELECTRIC Hazardous Location Circuit Breaker is a 3-pole enclosed circuit breaker with a 250/JD frame size, rated for 600V AC and a maximum AIR rating of 65kA at 240V AC. It includes a Cutler-Hammer…

SKU 3G-OTH-21635

Brand
APPLETON ELECTRIC
Item
Hazardous Location Circuit Breaker: 3 Poles, 250 A Amps, 600V AC
Category
Hazardous Location Enclosed Circuit Breakers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPLETON ELECTRIC
Manufacturer Part Number
AEFB23625C
Type
65kA at 240V AC
AC
600V
Amps
250 A
Frame Size
250/JD
Max. AIR Rating
65kA at 240V AC
AC Voltage Rating
600V AC
Circuit Breaker Included
Cutler-Hammer
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPLETON ELECTRIC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPLETON ELECTRIC Hazardous Location Circuit Breaker is a 3-pole enclosed circuit breaker with a 250/JD frame size, rated for 600V AC and a maximum AIR rating of 65kA at 240V AC. It includes a Cutler-Hammer circuit breaker (MPN AEFB23625C).

Frequently Asked Questions

What is the APPLETON ELECTRIC AEFB23625C hazardous location circuit breaker used for?

This 3-pole enclosed circuit breaker is designed for hazardous locations where flammable gases or dusts may be present. It provides overcurrent protection and disconnection for 600V AC industrial equipment in oil refineries, chemical plants, and grain handling facilities.

What are the specifications of the APPLETON ELECTRIC AEFB23625C circuit breaker?

The AEFB23625C is a 3-pole, 250 A enclosed circuit breaker with a 250/JD frame size. It is rated for 600V AC and has a maximum AIR rating of 65kA at 240V AC. The unit includes a Cutler-Hammer circuit breaker inside the Appleton enclosure.

Where to buy the APPLETON ELECTRIC AEFB23625C hazardous location circuit breaker worldwide?

3G Electric supplies the APPLETON ELECTRIC AEFB23625C hazardous location circuit breaker to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for pricing and lead time on this Cutler-Hammer equipped unit.

How to select the correct frame size for an APPLETON ELECTRIC hazardous location circuit breaker?

Select the frame size based on the continuous current rating and available fault current. The AEFB23625C uses a 250/JD frame for 250 A applications. Verify the system voltage (600V AC max) and the available short-circuit current does not exceed 65kA at 240V AC.
