APPLETON ELECTRIC Tumbler Switch: 1 Gang, 2-Pole, 20 A, 277 V AC, Dead-End Hub
The APPLETON ELECTRIC EDS150-F2 is a one-gang front lever tumbler switch, 2-pole, 20 A, 277 V AC, with a dead-end hub and 1/2 in hub size. 3G Electric interprets your demand for this industrial switch and delivers it…
SKU 3G-OTH-31322
Need installation or engineering help?
Ask a question
Product Description
The APPLETON ELECTRIC EDS150-F2 is a one-gang front lever tumbler switch, 2-pole, 20 A, 277 V AC, with a dead-end hub and 1/2 in hub size. 3G Electric interprets your demand for this industrial switch and delivers it with specialist support across 14 departments, including electrical and controls.
Frequently Asked Questions
What is the APPLETON ELECTRIC EDS150-F2 tumbler switch used for?
The APPLETON ELECTRIC EDS150-F2 is a one-gang front lever tumbler switch used for industrial on/off control of lighting and equipment in hazardous or demanding environments. Its dead-end hub and 1/2 in hub size simplify conduit installation, making it suitable for plants, refineries, and processing facilities.
What are the specifications of the APPLETON ELECTRIC EDS150-F2?
The APPLETON ELECTRIC EDS150-F2 is a 2-pole, 20 A, 277 V AC tumbler switch with a dead-end hub and 1/2 in hub size. It is a one-gang front lever design, part number EDS150-F2. These ratings ensure reliable switching for industrial branch circuits up to 277 V AC.
Where to buy the APPLETON ELECTRIC EDS150-F2 worldwide?
3G Electric supplies the APPLETON ELECTRIC EDS150-F2 tumbler switch to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this genuine industrial switch.
How to install the APPLETON ELECTRIC EDS150-F2 tumbler switch?
Install the APPLETON ELECTRIC EDS150-F2 by mounting it to a standard 1/2 in conduit hub using the dead-end hub connection. Ensure power is off, wire the 2-pole contacts per the wiring diagram, and secure the front lever. Follow NEC and local codes for hazardous-location installations.
