APPLETON ELECTRIC Conduit Outlet Body: Iron, 3/4 in Trade Size, X Body, 23 cu in Body Capacity - Round Body - Type Access Fittings
APPLETON ELECTRICRound Body - Type Access Fittings

APPLETON ELECTRIC Conduit Outlet Body: Iron, 3/4 in Trade Size, X Body, 23 cu in Body Capacity

The APPLETON ELECTRIC Conduit Outlet Body is a round body Type Access Fitting made of iron, designed for use with threaded RMC. It features a 3/4 in trade size, X Body configuration, 23 cu in body capacity, and a…

SKU 3G-OTH-06468

Brand
APPLETON ELECTRIC
Item
Conduit Outlet Body: Iron, 3/4 in Trade Size, X Body, 23 cu in Body Capacity
Category
Round Body - Type Access Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPLETON ELECTRIC
Manufacturer Part Number
JBDX-75
Type
X Body, 23 cu in Body Capacity, Threaded Hub
Finish
Triple Coat Epoxy Coating
Hub Style
Threaded
Trade Size
3/4 in
For Use With
Threaded RMC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPLETON ELECTRIC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPLETON ELECTRIC Conduit Outlet Body is a round body Type Access Fitting made of iron, designed for use with threaded RMC. It features a 3/4 in trade size, X Body configuration, 23 cu in body capacity, and a threaded hub style. The unit is finished with a Triple Coat Epoxy Coating.

Frequently Asked Questions

What is the APPLETON ELECTRIC Conduit Outlet Body JBDX-75 used for?

The APPLETON ELECTRIC Conduit Outlet Body JBDX-75 is used to provide access to conductors in threaded rigid metal conduit (RMC) systems. It is commonly installed in industrial and commercial electrical distribution networks for pulling, splicing, or turning conductors, ensuring code-compliant wiring maintenance.

What are the specifications of the APPLETON ELECTRIC JBDX-75?

The JBDX-75 is a 3/4 in trade size, X Body conduit outlet body made of iron with a Triple Coat Epoxy Coating. It has a 23 cu in body capacity and a threaded hub style. It is designed for use with threaded RMC and is manufactured by APPLETON ELECTRIC.

Where to buy the APPLETON ELECTRIC JBDX-75 worldwide?

You can source the APPLETON ELECTRIC JBDX-75 conduit outlet body through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring you receive genuine APPLETON ELECTRIC fittings for your project.

How to install the APPLETON ELECTRIC JBDX-75 conduit outlet body?

Install the JBDX-75 by threading it onto threaded RMC using standard conduit wrenches. Ensure the Triple Coat Epoxy Coating is not damaged during installation. Apply thread sealant to joints for moisture resistance. Follow NEC guidelines for conductor fill and support spacing. Always verify the body capacity of 23 cu in meets your conductor count.

Used in

Common applications for APPLETON ELECTRIC
Oil and gas refineries — Appleton Electric EDSC21MC2 manual motor switch for controlling pumps in Class I, Division 1 areas
Chemical processing plants — Appleton Electric AEAB13420C hazardous location circuit breaker for motor protection in volatile environments
Pharmaceutical manufacturing — Appleton Electric FSK-1VDR weatherproof cover for duplex receptacles in washdown zones
Wastewater treatment facilities — Appleton Electric UNY250R-A aluminum conduit union for corrosion-resistant connections
Mining operations — Appleton Electric EDSC277-SA tandem 2-gang box for junction points in hazardous dust locations
Food and beverage processing — Appleton Electric JBK-75 iron cover for conduit access fittings in wet or dusty areas
