APPLETON ELECTRIC Conduit Outlet Body: Iron, GR, 1 1/2 in Trade Size, L Body - L Round Body - 90° Elbow Type
APPLETON ELECTRICL Round Body - 90° Elbow Type

APPLETON ELECTRIC Conduit Outlet Body: Iron, GR, 1 1/2 in Trade Size, L Body

The Appleton Electric GRL150 is an L-shaped, 90° elbow conduit outlet body made of iron with a triple-coat epoxy finish. Designed for use with threaded IMC, it features a 1-1/2 in trade size, female threaded hubs, a…

SKU 3G-OTH-05003

Brand
APPLETON ELECTRIC
Item
Conduit Outlet Body: Iron, GR, 1 1/2 in Trade Size, L Body
Category
L Round Body - 90° Elbow Type
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPLETON ELECTRIC
Manufacturer Part Number
GRL150
Series
For Standard Body
Type
GR, L Body, 72 cu in Body Capacity
Material
Iron
Finish
Triple Coat Epoxy Coating
Includes
Grounding Screw
Back Type
Round
Body Type
Conduit Outlet Body
Hub Style
Threaded
Standards
UL 886
Body Style
L
Trade Size
1 1/2 in
For Use With
Threaded IMC
Thread Gender
Female
Cover Included
Yes
Connection Type
Threaded
Hazardous Location
Yes
Compatible Conduit Trade Size
1-1/2 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPLETON ELECTRIC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The Appleton Electric GRL150 is an L-shaped, 90° elbow conduit outlet body made of iron with a triple-coat epoxy finish. Designed for use with threaded IMC, it features a 1-1/2 in trade size, female threaded hubs, a round back, and includes a grounding screw. This UL 886-listed body is suitable for hazardous locations and comes with a cover.

Frequently Asked Questions

What is the Appleton Electric GRL150 conduit outlet body used for?

The Appleton Electric GRL150 is an L-shaped, 90° elbow conduit outlet body used to pull, splice, or route conductors in threaded IMC systems. Its iron construction and triple-coat epoxy finish make it suitable for hazardous locations, providing a secure junction point in industrial electrical installations.

What are the specifications of the Appleton GRL150?

The Appleton GRL150 has a 1-1/2 in trade size, female threaded hubs, a round back, and a 72 cu in body capacity. It is made of iron with a triple-coat epoxy coating, includes a grounding screw and cover, and is UL 886 listed for hazardous locations. It is designed for use with threaded IMC.

Where to buy the Appleton GRL150 conduit outlet body worldwide?

3G Electric supplies the Appleton GRL150 conduit outlet body worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us to source this UL 886-listed L-body for your hazardous-location electrical project.

How to install the Appleton GRL150 conduit outlet body?

Install the Appleton GRL150 by threading it onto threaded IMC conduit using the female hubs. Ensure the grounding screw is connected per local code. Secure the cover with the included hardware. For hazardous locations, verify the seal and follow NEC guidelines for conduit bodies in classified areas.
