APPLETON ELECTRIC Conduit Outlet Body: Aluminum, GRU, 1 in Trade Size, XAT Body - X, XAT and XTF Round Body - Cross Type
APPLETON ELECTRICX, XAT and XTF Round Body - Cross Type

APPLETON ELECTRIC Conduit Outlet Body: Aluminum, GRU, 1 in Trade Size, XAT Body

The APPLETON ELECTRIC Conduit Outlet Body is an aluminum XAT round-body cross type for use with threaded IMC. This UL Listed unit features a 1 in trade size, female threaded hubs, a powder-coated finish, and includes…

SKU 3G-OTH-06470

Brand
APPLETON ELECTRIC
Item
Conduit Outlet Body: Aluminum, GRU, 1 in Trade Size, XAT Body
Category
X, XAT and XTF Round Body - Cross Type
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPLETON ELECTRIC
Manufacturer Part Number
GRU100-A
Series
For Standard Body
Type
GRU, XAT Body, 17.5 cu in Body Capacity
Material
Aluminum
Finish
Powder Coated
Back Type
Round
Body Type
Conduit Outlet Body
Hub Style
Threaded
Standards
UL Listed for Class I, Division 1 and 2, Groups C, D, Class II, Division 1 and 2, Groups E, F, G, and Class III
Body Style
XAT
Trade Size
1 in
For Use With
Threaded IMC
Thread Gender
Female
Cover Included
Yes
Connection Type
Threaded
Gasket Included
Yes
Special Features
Other
Hazardous Location
Yes
Compatible Conduit Trade Size
1 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPLETON ELECTRIC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPLETON ELECTRIC Conduit Outlet Body is an aluminum XAT round-body cross type for use with threaded IMC. This UL Listed unit features a 1 in trade size, female threaded hubs, a powder-coated finish, and includes a cover and gasket. It is rated for hazardous locations, meeting standards for Class I, Division 1 and 2, Groups C, D; Class II, Division 1 and 2, Groups E, F, G; and Class III.

Frequently Asked Questions

What is the Appleton Electric GRU100-A conduit outlet body used for?

The Appleton Electric GRU100-A is an aluminum XAT round-body cross type conduit outlet body used for pulling, splicing, and routing conductors in threaded IMC systems. It is rated for hazardous locations including Class I, Division 1 and 2, Groups C, D; Class II, Division 1 and 2, Groups E, F, G; and Class III.

What are the specifications of the Appleton Electric GRU100-A?

The GRU100-A has a 1 in trade size, female threaded hubs, XAT body style, 17.5 cu in body capacity, and a powder-coated aluminum finish. It includes a cover and gasket, is UL Listed for hazardous locations, and is compatible with threaded IMC conduit.

Where to buy the Appleton Electric GRU100-A worldwide?

3G Electric supplies and delivers the Appleton Electric GRU100-A conduit outlet body worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this UL Listed hazardous-location fitting.

How to install the Appleton Electric GRU100-A conduit outlet body?

Install the GRU100-A by threading it onto threaded IMC conduit using the female hubs. Ensure the cover and gasket are properly seated to maintain the hazardous-location seal. Follow NEC guidelines for conductor fill and support. Always verify compatibility with your specific Class and Group rating before installation.
