APPROVED VENDOR Open Barrel Splice: 6 AWG Wire Size, Blue Code, 1.01 in, Copper Barrel - Crimped Butt Splice Compression Connectors
APPROVED VENDORCrimped Butt Splice Compression Connectors

APPROVED VENDOR Open Barrel Splice: 6 AWG Wire Size, Blue Code, 1.01 in, Copper Barrel

The APPROVED VENDOR Open Barrel Splice is a crimped butt splice compression connector designed for 6 AWG wire size. It features a copper barrel, a blue color code, and a die code of 24, with a length of 1.01 inches…

SKU 3G-OTH-16816

Brand
APPROVED VENDOR
Item
Open Barrel Splice: 6 AWG Wire Size, Blue Code, 1.01 in, Copper Barrel
Category
Crimped Butt Splice Compression Connectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
22EZ16
Type
Blue Code, 1.01 in, Copper Barrel
Die
24
Die Code
24
Color Code
Blue
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Open Barrel Splice is a crimped butt splice compression connector designed for 6 AWG wire size. It features a copper barrel, a blue color code, and a die code of 24, with a length of 1.01 inches. This connector is identified by manufacturer part number 22EZ16.

Frequently Asked Questions

What is the APPROVED VENDOR Open Barrel Splice used for?

The APPROVED VENDOR Open Barrel Splice is used to join two 6 AWG wires in electrical installations. It is a crimped butt splice compression connector with a copper barrel, blue color code, and die code 24. Common applications include industrial wiring, panel building, and maintenance tasks requiring reliable, permanent wire connections.

What are the specifications of the APPROVED VENDOR Open Barrel Splice 22EZ16?

The APPROVED VENDOR Open Barrel Splice 22EZ16 is designed for 6 AWG wire size. It has a copper barrel, blue color code, die code 24, and a length of 1.01 inches. The manufacturer part number is 22EZ16. This crimped butt splice compression connector ensures a secure, low-resistance connection when used with the correct crimping die.

Where to buy the APPROVED VENDOR Open Barrel Splice 22EZ16 worldwide?

You can source the APPROVED VENDOR Open Barrel Splice 22EZ16 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply this connector to procurement teams and plant engineers internationally.

How to install the APPROVED VENDOR Open Barrel Splice 22EZ16?

To install the APPROVED VENDOR Open Barrel Splice 22EZ16, strip 6 AWG wire insulation to the barrel length, insert the wire into the open barrel, and crimp using a tool with die code 24. Ensure the crimp is centered and fully compressed for a gas-tight connection. Follow standard electrical safety practices and manufacturer guidelines for best results.
