APPROVED VENDOR Open Barrel Splice: 250 kcmil Wire Size, Yellow Code, 3.41 in, Copper Barrel - Crimped Butt Splice Compression Connectors
APPROVED VENDORCrimped Butt Splice Compression Connectors

APPROVED VENDOR Open Barrel Splice: 250 kcmil Wire Size, Yellow Code, 3.41 in, Copper Barrel

The APPROVED VENDOR Open Barrel Splice is a crimped butt splice compression connector for 250 kcmil wire size. It features a copper barrel, a yellow color code, and a Die Code of 62. This connector is identified by…

SKU 3G-OTH-17698

Brand
APPROVED VENDOR
Item
Open Barrel Splice: 250 kcmil Wire Size, Yellow Code, 3.41 in, Copper Barrel
Category
Crimped Butt Splice Compression Connectors
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
22EZ39
Type
Yellow Code, 3.41 in, Copper Barrel
Die
62
Die Code
62
Color Code
Yellow
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Open Barrel Splice is a crimped butt splice compression connector for 250 kcmil wire size. It features a copper barrel, a yellow color code, and a Die Code of 62. This connector is identified by manufacturer part number 22EZ39.

Frequently Asked Questions

What is the APPROVED VENDOR Open Barrel Splice used for?

The APPROVED VENDOR Open Barrel Splice is a crimped butt splice compression connector used to join two 250 kcmil copper conductors in electrical power distribution, industrial control panels, and heavy equipment wiring. Its open-barrel design allows easy conductor insertion before crimping with a compatible 62 die tool.

What are the specifications of the APPROVED VENDOR Open Barrel Splice 22EZ39?

The APPROVED VENDOR Open Barrel Splice (MPN 22EZ39) is rated for 250 kcmil wire size, has a copper barrel, yellow color code, and a Die Code of 62. Its overall length is 3.41 inches. It is a crimped butt splice compression connector designed for permanent, low-resistance splices in heavy-gauge copper conductors.

Where to buy the APPROVED VENDOR Open Barrel Splice 22EZ39 worldwide?

3G Electric supplies the APPROVED VENDOR Open Barrel Splice 22EZ39 to customers worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and a quote for your region.

How to install the APPROVED VENDOR Open Barrel Splice?

Strip the 250 kcmil conductor to the recommended length, insert it fully into the copper barrel, and crimp using a compression tool with a 62 die. Ensure the yellow color code matches the die size. Follow standard crimping practices for butt splices to achieve a secure, low-resistance connection.
