APPROVED VENDOR Cylinder Mold: Cylinder Mold, Base Plate, Steel, 8 in Overall Ht - Cylinder Molds
APPROVED VENDORCylinder Molds

APPROVED VENDOR Cylinder Mold: Cylinder Mold, Base Plate, Steel, 8 in Overall Ht

The APPROVED VENDOR Cylinder Mold is a steel cylinder mold that includes a base plate. It has an overall height of 8 inches and an overall diameter of 4 inches, with manufacturer part number 5DNU7.

SKU 3G-OTH-170484

Brand
APPROVED VENDOR
Item
Cylinder Mold: Cylinder Mold, Base Plate, Steel, 8 in Overall Ht
Category
Cylinder Molds
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
5DNU7
Type
Base Plate, Steel
Includes
Base Plate
Overall Ht
8 in
Overall Dia
4 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Cylinder Mold is a steel cylinder mold that includes a base plate. It has an overall height of 8 inches and an overall diameter of 4 inches, with manufacturer part number 5DNU7.

Frequently Asked Questions

What is the APPROVED VENDOR Cylinder Mold used for?

The APPROVED VENDOR Cylinder Mold is used in construction materials testing to form cylindrical concrete or mortar specimens. Its steel base plate provides a stable foundation for casting samples that are later tested for compressive strength. This mold is common in quality-control labs and field-testing applications.

What are the specifications of the APPROVED VENDOR Cylinder Mold 5DNU7?

The APPROVED VENDOR Cylinder Mold model 5DNU7 has an overall height of 8 inches and an overall diameter of 4 inches. It includes a steel base plate and is made of steel. The manufacturer part number is 5DNU7. These dimensions are standard for preparing 4x8-inch concrete test cylinders.

Where to buy the APPROVED VENDOR Cylinder Mold worldwide?

3G Electric supplies the APPROVED VENDOR Cylinder Mold worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time. We source and deliver this mold to any country.

How to maintain the APPROVED VENDOR Cylinder Mold?

After each use, clean the steel mold and base plate thoroughly with a wire brush to remove concrete residue. Apply a light coat of oil to prevent rust. Store in a dry area. Inspect for dents or warping before reuse. Proper maintenance extends mold life and ensures accurate test specimens.
