APPROVED VENDOR Potential Relay: 295V AC to 315V AC Pick Up, 135V AC Drop Out, Any Position - Fixed-Potential Relay
APPROVED VENDORFixed-Potential Relay

APPROVED VENDOR Potential Relay: 295V AC to 315V AC Pick Up, 135V AC Drop Out, Any Position

The APPROVED VENDOR Fixed-Potential Relay (SKU 5MLZ5) is a SPST relay with a pick-up voltage range of 295V AC to 315V AC and a maximum drop-out voltage of 135V AC. It features a coil voltage of 500V AC and is…

SKU 3G-OTH-68476

Brand
APPROVED VENDOR
Item
Potential Relay: 295V AC to 315V AC Pick Up, 135V AC Drop Out, Any Position
Category
Fixed-Potential Relay
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
5MLZ5
Type
Any Position
AC
500V
AC Drop Out
135V
Coil Voltage
500V AC
Contact Form
SPST
Maximum Drop Out Voltage
135V AC
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Fixed-Potential Relay (SKU 5MLZ5) is a SPST relay with a pick-up voltage range of 295V AC to 315V AC and a maximum drop-out voltage of 135V AC. It features a coil voltage of 500V AC and is designed for any mounting position.

Frequently Asked Questions

What is a fixed-potential relay used for?

A fixed-potential relay, like the APPROVED VENDOR 5MLZ5, is used in motor-start circuits to disconnect the start winding once the motor reaches a preset speed. It is commonly applied in HVAC compressors, pumps, and refrigeration equipment where reliable voltage-based switching is required.

What are the specifications of the APPROVED VENDOR 5MLZ5 relay?

The APPROVED VENDOR 5MLZ5 is a SPST fixed-potential relay with a pick-up voltage range of 295V AC to 315V AC and a maximum drop-out voltage of 135V AC. Its coil voltage is 500V AC, and it is designed for any mounting position.

Where to buy the APPROVED VENDOR 5MLZ5 relay worldwide?

You can source the APPROVED VENDOR 5MLZ5 relay through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring the relay reaches your facility reliably.

How to select a fixed-potential relay for a motor circuit?

Select a fixed-potential relay by matching its pick-up voltage to the motor's start-winding voltage and its drop-out voltage to the run condition. For the APPROVED VENDOR 5MLZ5, ensure your circuit operates within 295V AC to 315V AC pick-up and 135V AC drop-out, with a 500V AC coil rating.
