APPROVED VENDOR Helical Insert: Tanged Tang Style, Free-Running, 7/16"-20 Thread Size, Plain - Free-Running Tanged Helical Inserts
APPROVED VENDORFree-Running Tanged Helical Inserts

APPROVED VENDOR Helical Insert: Tanged Tang Style, Free-Running, 7/16"-20 Thread Size, Plain

The APPROVED VENDOR Helical Insert is a free-running, tanged tang style insert with a 7/16"-20 thread size, fine thread, and right-hand orientation. Made from 18-8 metal, this plain insert offers a tensile strength…

SKU 3G-OTH-598944

Brand
APPROVED VENDOR
Item
Helical Insert: Tanged Tang Style, Free-Running, 7/16"-20 Thread Size, Plain
Category
Free-Running Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
3534-7/16X1.0D
Type
Free-Running, Plain, 10 PK
Thread Size
7/16"-20
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Helical Insert is a free-running, tanged tang style insert with a 7/16"-20 thread size, fine thread, and right-hand orientation. Made from 18-8 metal, this plain insert offers a tensile strength of 200,000 psi and comes in a 10-pack (MPN 3534-7/16X1.0D).

Frequently Asked Questions

What is an APPROVED VENDOR helical insert used for?

An APPROVED VENDOR helical insert repairs or reinforces tapped holes in metal. It creates a strong, wear-resistant 7/16"-20 fine thread in softer materials like aluminum or cast iron. This free-running, tanged tang style insert is ideal for automotive, aerospace, and industrial maintenance applications where thread integrity is critical.

What are the specifications of the APPROVED VENDOR 3534-7/16X1.0D helical insert?

This helical insert has a 7/16"-20 thread size, fine thread, right-hand orientation, and a tensile strength of 200,000 psi. It is made from 18-8 metal, plain finish, and comes in a 10-pack. The manufacturer part number is 3534-7/16X1.0D, and it is an inch-series, free-running, tanged tang style insert.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies APPROVED VENDOR helical inserts worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us to order the 3534-7/16X1.0D 10-pack or other thread sizes. We source genuine parts and support your procurement needs across industries.

How to install a tanged tang helical insert?

To install a tanged tang helical insert, drill out the damaged thread to the specified tap drill size, then tap the hole with the correct STI tap. Use a tang-style installation tool to wind the insert into the hole until it sits slightly below the surface. Break off the tang with a punch. Always follow the manufacturer's instructions for torque and depth.
