APPROVED VENDOR Helical Insert: Tanged Tang Style, Free-Running, 3/4"-16 Thread Size, Plain - Free-Running Tanged Helical Inserts
APPROVED VENDORFree-Running Tanged Helical Inserts

APPROVED VENDOR Helical Insert: Tanged Tang Style, Free-Running, 3/4"-16 Thread Size, Plain

The APPROVED VENDOR Helical Insert is a free-running, tanged tang style insert with a 3/4"-16 thread size, fine thread, and right-hand orientation. Supplied in a 5-pack, this plain, 18-8 stainless steel insert (MPN…

SKU 3G-OTH-599170

Brand
APPROVED VENDOR
Item
Helical Insert: Tanged Tang Style, Free-Running, 3/4"-16 Thread Size, Plain
Category
Free-Running Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
3534-3/4X1.5D
Type
Free-Running, Plain, 5 PK
Thread Size
3/4"-16
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Helical Insert is a free-running, tanged tang style insert with a 3/4"-16 thread size, fine thread, and right-hand orientation. Supplied in a 5-pack, this plain, 18-8 stainless steel insert (MPN 3534-3/4X1.5D) offers a tensile strength of 200,000 psi. 3G Electric interprets your demand for genuine industrial fasteners and delivers this insert as part of our broad supply across 14 industrial departments — with specialist depth in combustion, pumps and controls as an authorised distributor for brands like FBR, Interpump, Riello, Beckett, Schneider, ABB, Siemens, SKF, Festo, and Fluke.

Frequently Asked Questions

What is an APPROVED VENDOR helical insert used for?

This free-running tanged helical insert repairs or reinforces tapped holes in metal assemblies, providing a strong 18-8 stainless steel thread. It is commonly used in industrial machinery, automotive, and aerospace applications where a 3/4"-16 fine thread is required.

What are the specifications of the APPROVED VENDOR 3534-3/4X1.5D helical insert?

This insert has a 3/4"-16 thread size, fine thread, right-hand orientation, and a tensile strength of 200,000 psi. It is made of 18-8 stainless steel, plain finish, and comes in a 5-pack. The manufacturer part number is 3534-3/4X1.5D.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies and delivers the APPROVED VENDOR helical insert worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to ensure your order arrives at your facility, wherever it is located.

How to install a tanged helical insert?

Installation requires drilling the damaged hole to the specified tap drill size, tapping with a compatible STI tap, then winding the insert into the hole using a tang drive tool. After installation, break off the tang with a punch. Always follow the manufacturer's instructions for best results.
