APPROVED VENDOR Helical Insert: Tanged Tang Style, Free-Running, M2.5-0.45 Thread Size - Free-Running Tanged Helical Inserts
APPROVED VENDORFree-Running Tanged Helical Inserts

APPROVED VENDOR Helical Insert: Tanged Tang Style, Free-Running, M2.5-0.45 Thread Size

APPROVED VENDOR Helical Insert: Tanged Tang Style is a free-running, tanged helical insert with M2.5-0.45 thread size, plain finish, and right-hand coarse metric threads. Made from 18-8 metal with 200,000 psi tensile…

SKU 3G-OTH-599096

Brand
APPROVED VENDOR
Item
Helical Insert: Tanged Tang Style, Free-Running, M2.5-0.45 Thread Size
Category
Free-Running Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
3520-2.50X2.0D
Type
Free-Running, M2.5-0.45 Thread Size, Plain, 10 PK
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

APPROVED VENDOR Helical Insert: Tanged Tang Style is a free-running, tanged helical insert with M2.5-0.45 thread size, plain finish, and right-hand coarse metric threads. Made from 18-8 metal with 200,000 psi tensile strength, this 10-pack (MPN 3520-2.50X2.0D) provides a reliable thread repair solution for industrial applications.

Frequently Asked Questions

What is an APPROVED VENDOR helical insert used for?

An APPROVED VENDOR helical insert repairs or reinforces internal threads in metal components. This free-running tanged style with M2.5-0.45 coarse threads restores stripped threads in industrial machinery, automotive assemblies, and equipment housings, providing a durable 18-8 stainless steel thread with 200,000 psi tensile strength.

What are the specifications of the APPROVED VENDOR 3520-2.50X2.0D helical insert?

This helical insert has M2.5-0.45 thread size, right-hand coarse metric threads, plain finish, and tanged tang style. It is made from 18-8 metal with 200,000 psi tensile strength. The pack contains 10 pieces (MPN 3520-2.50X2.0D) and is manufactured by APPROVED VENDOR.

Where to buy APPROVED VENDOR helical inserts in worldwide?

3G Electric supplies APPROVED VENDOR helical inserts worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us to source the M2.5-0.45 free-running tanged insert (MPN 3520-2.50X2.0D) or other thread repair solutions.

How to install an APPROVED VENDOR tanged helical insert?

Drill out the damaged thread to the specified tap drill size, tap the hole with the correct STI tap, then use a tang break-off tool to insert the helical coil. After installation, break off the tang with a punch. Ensure the insert sits slightly below the surface for proper thread engagement.
