APPROVED VENDOR Helical Insert: Tanged Tang Style, Free-Running, M8-1.25 Thread Size, Plain - Free-Running Tanged Helical Inserts
APPROVED VENDORFree-Running Tanged Helical Inserts

APPROVED VENDOR Helical Insert: Tanged Tang Style, Free-Running, M8-1.25 Thread Size, Plain

The APPROVED VENDOR Helical Insert is a free-running tanged tang style insert with M8-1.25 coarse right-hand threads, made from 18-8 metal and rated to 200,000 psi. Supplied in a plain finish, 10-pack (MPN…

SKU 3G-OTH-599041

Brand
APPROVED VENDOR
Item
Helical Insert: Tanged Tang Style, Free-Running, M8-1.25 Thread Size, Plain
Category
Free-Running Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
3520-8.00X1.5D
Type
Free-Running, M8-1.25 Thread Size, Plain, 10 PK
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Helical Insert is a free-running tanged tang style insert with M8-1.25 coarse right-hand threads, made from 18-8 metal and rated to 200,000 psi. Supplied in a plain finish, 10-pack (MPN 3520-8.00X1.5D), it provides a reliable thread repair or reinforcement solution for metric applications.

Frequently Asked Questions

What is an APPROVED VENDOR helical insert used for?

The APPROVED VENDOR helical insert repairs or reinforces stripped internal threads in metal components. Its free-running tanged tang design allows easy installation in metric M8-1.25 coarse applications, restoring thread strength to 200,000 psi. It is commonly used in automotive, machinery, and industrial equipment maintenance.

What are the specifications of the APPROVED VENDOR helical insert 3520-8.00X1.5D?

This helical insert has M8-1.25 coarse right-hand threads, is made from 18-8 metal, and rated to 200,000 psi. It comes in a plain finish, metric size, and is supplied as a 10-pack. The tang style is tanged for free-running installation, suitable for thread repair in metal substrates.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies APPROVED VENDOR helical inserts worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us to order the M8-1.25 10-pack (MPN 3520-8.00X1.5D) or other thread repair inserts for your application.

How to install a tanged helical insert?

To install a tanged helical insert, drill out the damaged thread to the specified tap drill size, tap the hole with the correct STI tap, then use a tang installation tool to wind the insert into the hole until it sits slightly below the surface. Break off the tang after installation for a free-running thread.
