APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, #8-36 Thread Size, Plain - Screw-Locking Tanged Helical Inserts
APPROVED VENDORScrew-Locking Tanged Helical Inserts

APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, #8-36 Thread Size, Plain

APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, #8-36 Thread Size, Plain, 10 PK (MPN 3534-8GX1.5DSL). This inch-system, right-hand thread insert is made from 18-8 material with a tensile strength of…

SKU 3G-OTH-528947

Brand
APPROVED VENDOR
Item
Helical Insert: Tanged Tang Style, Screw-Locking, #8-36 Thread Size, Plain
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
3534-8GX1.5DSL
Type
Screw-Locking, #8-36 Thread Size, Plain, 10 PK
Tensile Strength
200,000 psi
Finish Type
Plain
Thread Type
Fine
STI Tap Size
#8-36
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, #8-36 Thread Size, Plain, 10 PK (MPN 3534-8GX1.5DSL). This inch-system, right-hand thread insert is made from 18-8 material with a tensile strength of 200,000 psi, compatible with metal substrates. It uses a fine thread type and requires an STI tap size of #8-36.

Frequently Asked Questions

What is an APPROVED VENDOR helical insert used for?

An APPROVED VENDOR helical insert repairs or reinforces threads in metal components. Its screw-locking design resists vibration loosening, making it ideal for demanding industrial applications where joint integrity is critical.

What are the specifications of the APPROVED VENDOR 3534-8GX1.5DSL helical insert?

This tanged tang-style insert has a #8-36 fine thread, right-hand direction, and 18-8 material with 200,000 psi tensile strength. It requires an STI tap size of #8-36 and is compatible with metal substrates. Sold in a 10-pack.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies APPROVED VENDOR helical inserts worldwide. We handle full logistics and customs clearance to deliver these screw-locking inserts to your facility, ensuring you get the correct thread repair solution for your application.

How to install a tanged helical insert?

Installation requires drilling to the specified STI tap size (#8-36), tapping the hole, then winding the insert onto a tang drive tool until it sits below the surface. Break off the tang after installation. Always follow the manufacturer's instructions for best results.
