APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, M4-0.70 Thread Size, Plain - Screw-Locking Tanged Helical Inserts
APPROVED VENDORScrew-Locking Tanged Helical Inserts

APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, M4-0.70 Thread Size, Plain

APPROVED VENDOR Helical Insert: Tanged Tang Style is a screw-locking, tanged helical insert with M4-0.70 thread size, plain finish, and 18-8 material grade. It features a coarse right-hand thread, 200,000 psi tensile…

SKU 3G-OTH-528920

Brand
APPROVED VENDOR
Item
Helical Insert: Tanged Tang Style, Screw-Locking, M4-0.70 Thread Size, Plain
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
3520-4.00X1.0DSL
Type
Screw-Locking, M4-0.70 Thread Size, Plain, 10 PK
Tensile Strength
200,000 psi
Finish Type
Plain
Thread Type
Coarse
STI Tap Size
M4-0.70
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Metric
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

APPROVED VENDOR Helical Insert: Tanged Tang Style is a screw-locking, tanged helical insert with M4-0.70 thread size, plain finish, and 18-8 material grade. It features a coarse right-hand thread, 200,000 psi tensile strength, and is compatible with metal. Supplied in a 10-pack, this metric insert is designed for use with an M4-0.70 STI tap.

Frequently Asked Questions

What is an APPROVED VENDOR helical insert used for?

An APPROVED VENDOR helical insert repairs or strengthens threads in metal. This M4-0.70 screw-locking tanged style provides a durable 18-8 stainless steel thread with 200,000 psi tensile strength, ideal for industrial maintenance and assembly applications.

What are the specifications of the APPROVED VENDOR M4 helical insert?

This insert has M4-0.70 coarse right-hand threads, 18-8 material grade, plain finish, and 200,000 psi tensile strength. It requires an M4-0.70 STI tap and is supplied in a 10-pack. The screw-locking design prevents loosening under vibration.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies APPROVED VENDOR helical inserts worldwide. We handle full logistics and customs clearance to deliver this M4-0.70 screw-locking tanged insert to your facility. Contact us for availability and lead time on this 10-pack.

How to install an APPROVED VENDOR tanged helical insert?

Install using an M4-0.70 STI tap to cut threads, then insert the tanged insert with a driver tool. Break off the tang after installation. The screw-locking feature secures the insert in metal. Follow standard thread repair practices for best results.
