APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, M12-1.75 Thread Size - Screw-Locking Tanged Helical Inserts
APPROVED VENDORScrew-Locking Tanged Helical Inserts

APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, M12-1.75 Thread Size

The APPROVED VENDOR Helical Insert is a screw-locking, tanged tang style insert with M12-1.75 coarse thread size, plain finish, and 18-8 material grade. It offers a tensile strength of 200,000 psi, is compatible with…

SKU 3G-OTH-528819

Brand
APPROVED VENDOR
Item
Helical Insert: Tanged Tang Style, Screw-Locking, M12-1.75 Thread Size
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
3520-12.00X2.0DSL
Type
Screw-Locking, M12-1.75 Thread Size, Plain, 5 PK
Tensile Strength
200,000 psi
Finish Type
Plain
Thread Type
Coarse
STI Tap Size
M12-1.75
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Metric
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Helical Insert is a screw-locking, tanged tang style insert with M12-1.75 coarse thread size, plain finish, and 18-8 material grade. It offers a tensile strength of 200,000 psi, is compatible with metal, and comes in a 5 PK set. 3G Electric interprets customer demand and delivers this genuine industrial product across 14 departments, with specialist depth in combustion, pumps, and controls as an authorised distributor.

Frequently Asked Questions

What is the APPROVED VENDOR helical insert used for?

The APPROVED VENDOR helical insert is used to repair or reinforce internal threads in metal components. Its screw-locking design resists vibration loosening, making it suitable for demanding industrial applications across machining, power transmission, and material handling equipment.

What are the specifications of the APPROVED VENDOR helical insert?

This helical insert has M12-1.75 coarse thread size, 18-8 material grade, and a tensile strength of 200,000 psi. It is a screw-locking, tanged tang style with plain finish, right-hand thread direction, and compatible with metal. The pack contains 5 pieces.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies APPROVED VENDOR helical inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver genuine products to your facility. Contact us for availability and lead time on this M12-1.75 screw-locking insert.

How to install a tanged helical insert?

To install a tanged helical insert, drill out the damaged thread to the specified STI tap size (M12-1.75), tap the hole, then use a tang-style installation tool to wind the insert into place. After installation, break off the tang with a punch. Always follow the manufacturer's instructions for best results.
