APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, M24-3.00 Thread Size - Screw-Locking Tanged Helical Inserts
APPROVED VENDORScrew-Locking Tanged Helical Inserts

APPROVED VENDOR Helical Insert: Tanged Tang Style, Screw-Locking, M24-3.00 Thread Size

The APPROVED VENDOR Helical Insert is a screw-locking, tanged tang style insert with M24-3.00 thread size, plain finish, and right-hand coarse threads. It is made from 18-8 material grade with a tensile strength of…

SKU 3G-OTH-528899

Brand
APPROVED VENDOR
Item
Helical Insert: Tanged Tang Style, Screw-Locking, M24-3.00 Thread Size
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
3520-24.00X1.5DSL
Type
Screw-Locking, M24-3.00 Thread Size, Plain, Plain
Tensile Strength
200,000 psi
Finish Type
Plain
Thread Type
Coarse
STI Tap Size
M24-3.00
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Metric
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Helical Insert is a screw-locking, tanged tang style insert with M24-3.00 thread size, plain finish, and right-hand coarse threads. It is made from 18-8 material grade with a tensile strength of 200,000 psi, compatible with metal, and uses an STI tap size of M24-3.00 in metric measurement.

Frequently Asked Questions

What is an APPROVED VENDOR M24-3.00 helical insert used for?

This screw-locking tanged helical insert repairs or strengthens tapped holes in metal. It provides a durable 18-8 stainless steel thread with 200,000 psi tensile strength, ideal for high-stress industrial applications across machining, power transmission, and hydraulics.

What are the specifications of the APPROVED VENDOR 3520-24.00X1.5DSL helical insert?

The insert has M24-3.00 metric coarse threads, right-hand direction, plain finish, and requires an STI tap size M24-3.00. It is made from 18-8 stainless steel with 200,000 psi tensile strength, compatible with metal substrates.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies APPROVED VENDOR helical inserts worldwide. We handle full logistics, customs clearance, and delivery to your site. As a global industrial solutions provider, we source and deliver genuine parts across 14 departments including machining and fasteners.

How to install a tanged screw-locking helical insert?

Drill out the damaged thread to the specified STI tap size (M24-3.00), tap the hole with the corresponding STI tap, then wind the insert onto the installation tool and drive it into the tapped hole. Break off the tang after installation for a secure, locking thread.
