APPROVED VENDOR Metal Pipe Elbow: 45° Elbow, 1/4 in x 1/4 in, Class 1000, 1,000 psi - Nickel-Plated Threaded High-Pressure Pipe Fittings
APPROVED VENDORNickel-Plated Threaded High-Pressure Pipe Fittings

APPROVED VENDOR Metal Pipe Elbow: 45° Elbow, 1/4 in x 1/4 in, Class 1000, 1,000 psi

The APPROVED VENDOR Metal Pipe Elbow is a 45° elbow, nickel-plated threaded high-pressure pipe fitting. It is a 1/4 in x 1/4 in, Class 1000 fitting with a maximum operating pressure of 1,000 psi and a length of 1 in…

SKU 3G-OTH-477721

Brand
APPROVED VENDOR
Item
Metal Pipe Elbow: 45° Elbow, 1/4 in x 1/4 in, Class 1000, 1,000 psi
Category
Nickel-Plated Threaded High-Pressure Pipe Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
ZUSA-PF-9047
Type
1/4 in x 1/4 in, Class 1000, 1,000 psi
Lg
1 in
Maximum Operating Pressure
1,000 psi
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Metal Pipe Elbow is a 45° elbow, nickel-plated threaded high-pressure pipe fitting. It is a 1/4 in x 1/4 in, Class 1000 fitting with a maximum operating pressure of 1,000 psi and a length of 1 in (MPN ZUSA-PF-9047).

Frequently Asked Questions

What is the APPROVED VENDOR metal pipe elbow used for?

This 45° elbow is used to change the direction of high-pressure fluid or gas lines in industrial piping systems. It is suitable for applications requiring a compact, corrosion-resistant fitting, such as hydraulic, pneumatic, and instrumentation circuits, where nickel plating provides added durability.

What are the specifications of the APPROVED VENDOR 45° pipe elbow?

This fitting is a 45° elbow with 1/4 in x 1/4 in connections, Class 1000 rating, and a maximum operating pressure of 1,000 psi. It has a length of 1 in and is nickel-plated for corrosion resistance. The manufacturer part number is ZUSA-PF-9047.

Where to buy the APPROVED VENDOR metal pipe elbow worldwide?

3G Electric supplies the APPROVED VENDOR metal pipe elbow worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us to order this nickel-plated threaded high-pressure pipe fitting for your application.

How to install the APPROVED VENDOR 45° pipe elbow?

Apply thread sealant to the male threads and hand-tighten the elbow into the mating port. Use a wrench on the hex flats to achieve a leak-free seal, but avoid over-tightening to prevent thread damage. Always verify the system pressure does not exceed the 1,000 psi rating.
