APPROVED VENDOR Metal Pipe Elbow: 90° Elbow, 1/8 in x 1/8 in, Class 1000, 1,000 psi - Nickel-Plated Threaded High-Pressure Pipe Fittings
APPROVED VENDORNickel-Plated Threaded High-Pressure Pipe Fittings

APPROVED VENDOR Metal Pipe Elbow: 90° Elbow, 1/8 in x 1/8 in, Class 1000, 1,000 psi

The APPROVED VENDOR Metal Pipe Elbow is a 90° nickel-plated threaded high-pressure pipe fitting with a 1/8 in x 1/8 in size, Class 1000 rating, and a maximum operating pressure of 1,000 psi. It has a length of 3/4 in…

SKU 3G-OTH-477716

Brand
APPROVED VENDOR
Item
Metal Pipe Elbow: 90° Elbow, 1/8 in x 1/8 in, Class 1000, 1,000 psi
Category
Nickel-Plated Threaded High-Pressure Pipe Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
ZUSA-PF-9038
Type
1/8 in x 1/8 in, Class 1000, 1,000 psi
Lg
3/4 in
Maximum Operating Pressure
1,000 psi
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Metal Pipe Elbow is a 90° nickel-plated threaded high-pressure pipe fitting with a 1/8 in x 1/8 in size, Class 1000 rating, and a maximum operating pressure of 1,000 psi. It has a length of 3/4 in and is identified by manufacturer part number ZUSA-PF-9038.

Frequently Asked Questions

What is the APPROVED VENDOR ZUSA-PF-9038 metal pipe elbow used for?

This 90° nickel-plated threaded high-pressure pipe fitting is used to change flow direction in industrial piping systems. It suits applications requiring a compact 1/8 in x 1/8 in connection with a 1,000 psi maximum operating pressure, such as instrumentation or pneumatic lines.

What are the specifications of the APPROVED VENDOR ZUSA-PF-9038 elbow?

The ZUSA-PF-9038 is a 90° elbow with 1/8 in x 1/8 in NPT threads, Class 1000 rating, and a maximum operating pressure of 1,000 psi. It has a length of 3/4 in and is made of nickel-plated steel for corrosion resistance.

Where to buy the APPROVED VENDOR ZUSA-PF-9038 elbow worldwide?

3G Electric supplies the APPROVED VENDOR ZUSA-PF-9038 nickel-plated threaded high-pressure pipe elbow to customers worldwide. We handle full logistics, customs clearance, and delivery, ensuring you receive the correct fitting for your industrial application.

How to install the APPROVED VENDOR ZUSA-PF-9038 pipe elbow?

Apply thread sealant to the male NPT threads and hand-tighten the elbow into the mating fitting. Use a wrench on the hex flats to snug the connection without over-tightening, which can damage the nickel plating or threads. Always verify pressure rating compatibility.
