APPROVED VENDOR Self Locking Thread Insert: Thin Wall, 3/8"-24 Int Thrd Sz - Self-Locking Insert & Installation Tool Kits
APPROVED VENDORSelf-Locking Insert & Installation Tool Kits

APPROVED VENDOR Self Locking Thread Insert: Thin Wall, 3/8"-24 Int Thrd Sz

The APPROVED VENDOR Self Locking Thread Insert is a thin-wall, inch-system insert with a 1/2"-13 external thread (2A fit) and a 3/8"-24 internal thread (2B fit). It requires a 29/64 drill bit and a 1/2"-13 compatible…

SKU 3G-OTH-534019

Brand
APPROVED VENDOR
Item
Self Locking Thread Insert: Thin Wall, 3/8"-24 Int Thrd Sz
Category
Self-Locking Insert & Installation Tool Kits
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
EZ-310-624
Wall Type
Thin Wall
Ext Thrd Sz
1/2"-13
Int Thrd Sz
3/8"-24
Thread Type
Coarse
Drill Bit Size
29/64
Compatible Tap Size
1/2"-13
External Thread Fit
2A
Internal Thread Fit
2B
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Self Locking Thread Insert is a thin-wall, inch-system insert with a 1/2"-13 external thread (2A fit) and a 3/8"-24 internal thread (2B fit). It requires a 29/64 drill bit and a 1/2"-13 compatible tap, with coarse thread type. This self-locking insert is designed for thin-wall applications, providing a threaded repair or reinforcement solution.

Frequently Asked Questions

What is the APPROVED VENDOR Self Locking Thread Insert used for?

This thin-wall thread insert repairs or reinforces damaged internal threads in thin materials. It uses a 3/8"-24 internal thread (2B fit) and a 1/2"-13 external thread (2A fit), requiring a 29/64 drill bit and 1/2"-13 tap. It is suitable for industrial maintenance and assembly applications.

What are the specifications of the APPROVED VENDOR Self Locking Thread Insert?

The insert has a thin wall, inch system, coarse thread type, 1/2"-13 external thread (2A fit), and 3/8"-24 internal thread (2B fit). It requires a 29/64 drill bit and a 1/2"-13 compatible tap. The manufacturer part number is EZ-310-624.

Where to buy the APPROVED VENDOR Self Locking Thread Insert worldwide?

3G Electric supplies the APPROVED VENDOR Self Locking Thread Insert worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this thin-wall thread insert.

How to install the APPROVED VENDOR Self Locking Thread Insert?

Drill a hole using a 29/64 drill bit, then tap the hole with a 1/2"-13 tap. Insert the self-locking insert using a compatible installation tool, ensuring the external thread (2A fit) engages properly. Follow standard thread insert installation practices for thin-wall applications.
