APPROVED VENDOR Self Locking Thread Insert: Std Wall, 1/4"-20 Int Thrd Sz - Self-Locking Insert & Installation Tool Kits
APPROVED VENDORSelf-Locking Insert & Installation Tool Kits

APPROVED VENDOR Self Locking Thread Insert: Std Wall, 1/4"-20 Int Thrd Sz

The APPROVED VENDOR Self Locking Thread Insert is a standard-wall, inch-system insert with a 1/4"-20 internal thread size and a 7/16"-14 external thread size. It features coarse threads, a 2B internal thread fit, and…

SKU 3G-OTH-533994

Brand
APPROVED VENDOR
Item
Self Locking Thread Insert: Std Wall, 1/4"-20 Int Thrd Sz
Category
Self-Locking Insert & Installation Tool Kits
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
EZ-329-4
Wall Type
Standard Wall
Ext Thrd Sz
7/16"-14
Int Thrd Sz
1/4"-20
Thread Type
Coarse
Compatible Tap Size
7/16"-14
External Thread Fit
2A
Internal Thread Fit
2B
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Self Locking Thread Insert is a standard-wall, inch-system insert with a 1/4"-20 internal thread size and a 7/16"-14 external thread size. It features coarse threads, a 2B internal thread fit, and a 2A external thread fit, compatible with a 7/16"-14 tap (MPN EZ-329-4).

Frequently Asked Questions

What is an APPROVED VENDOR Self Locking Thread Insert used for?

This standard-wall thread insert repairs or reinforces tapped holes in metal assemblies. It provides a durable 1/4"-20 internal thread with a 2B fit, preventing loosening under vibration. Common in automotive, machinery, and industrial equipment maintenance.

What are the specifications of the APPROVED VENDOR EZ-329-4 thread insert?

The insert has a 1/4"-20 internal thread size and a 7/16"-14 external thread size, both coarse. It uses a 2B internal thread fit and a 2A external thread fit. Compatible tap size is 7/16"-14. System of measurement is inch.

Where to buy APPROVED VENDOR thread inserts worldwide?

3G Electric supplies the APPROVED VENDOR EZ-329-4 self-locking thread insert to customers worldwide. We handle full logistics, customs clearance, and delivery to your facility. Contact us for a quote and lead time on this standard-wall, inch-system insert.

How to install a self-locking thread insert?

Drill out the damaged thread to the recommended tap size (7/16"-14 for this insert), then tap the hole. Use a compatible installation tool to drive the insert until it sits slightly below the surface. The self-locking feature secures it without additional adhesives.
