APPROVED VENDOR Key Locking Insert: Heavy Wall, 4 Keys, M6-1.00 Int Thrd Sz, M12x1.25 Ext Thrd Sz - Mil. Spec. Key-Locking Inserts
APPROVED VENDORMil. Spec. Key-Locking Inserts

APPROVED VENDOR Key Locking Insert: Heavy Wall, 4 Keys, M6-1.00 Int Thrd Sz, M12x1.25 Ext Thrd Sz

The APPROVED VENDOR Key Locking Insert is a heavy-wall, mil. spec. insert with 4 keys, M6-1.00 internal thread size, M12x1.25 external thread size, plain finish, and coarse thread type. It meets Fed Std. H28/21 and…

SKU 3G-OTH-531782

Brand
APPROVED VENDOR
Item
Key Locking Insert: Heavy Wall, 4 Keys, M6-1.00 Int Thrd Sz, M12x1.25 Ext Thrd Sz
Category
Mil. Spec. Key-Locking Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
217-077365
Type
M6-1.00 Int Thrd Sz, M12x1.25 Ext Thrd Sz, Plain, 10 PK
Keys
4
Wall Type
Heavy Wall
Finish Type
Plain
Thread Type
Coarse
Industry Standards
Fed Std. H28/21, MJ Form
Compatible Tap Size
M12x1.25
External Thread Fit
2A
Internal Thread Fit
3B
Material Grade/Class
18-8
System of Measurement
Metric
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Key Locking Insert is a heavy-wall, mil. spec. insert with 4 keys, M6-1.00 internal thread size, M12x1.25 external thread size, plain finish, and coarse thread type. It meets Fed Std. H28/21 and MJ Form standards, with 2A external and 3B internal thread fits, made from 18-8 material, compatible with M12x1.25 tap size, and supplied in a 10-pack (MPN 217-077365).

Frequently Asked Questions

What is an APPROVED VENDOR key locking insert used for?

An APPROVED VENDOR key locking insert is used to repair or reinforce tapped threads in metal assemblies, especially where vibration or high loads are present. The heavy-wall design with 4 keys locks the insert in place, meeting mil. spec. standards for aerospace, defense, and industrial applications.

What are the specifications of the APPROVED VENDOR key locking insert 217-077365?

This insert has M6-1.00 internal thread size and M12x1.25 external thread size, with 2A external and 3B internal thread fits. It is made from 18-8 stainless steel, has a plain finish, coarse thread type, and meets Fed Std. H28/21 and MJ Form standards. Supplied in a 10-pack.

Where to buy APPROVED VENDOR key locking inserts worldwide?

3G Electric supplies APPROVED VENDOR key locking inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver to any international destination. Contact us for pricing and lead time on this 10-pack of heavy-wall inserts.

How to install a key locking insert?

Installation requires drilling out the damaged thread to the specified tap size (M12x1.25), tapping the hole, then threading the insert in using a compatible installation tool. The 4 keys are then set into the parent material to lock the insert. Always follow the manufacturer's torque and depth guidelines.
