APPROVED VENDOR Timing Belt Pulley: Trapezoidal, Bushed, For L Timing Belt Section - Bushed L Section Timing Belt Pulleys
APPROVED VENDORBushed L Section Timing Belt Pulleys

APPROVED VENDOR Timing Belt Pulley: Trapezoidal, Bushed, For L Timing Belt Section

The APPROVED VENDOR Timing Belt Pulley is a bushed L section trapezoidal timing belt pulley with a black oxide finish. It is designed for use with a split taper bushing and accommodates a 1-inch belt width…

SKU 3G-OTH-113730

Brand
APPROVED VENDOR
Item
Timing Belt Pulley: Trapezoidal, Bushed, For L Timing Belt Section
Category
Bushed L Section Timing Belt Pulleys
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
20LG100
Type
Bushed, For L Timing Belt Section, For 1 in Belt Wd
Finish
Black Oxide
Tooth Profile
Trapezoidal
For Bushing Type
Split Taper
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Timing Belt Pulley is a bushed L section trapezoidal timing belt pulley with a black oxide finish. It is designed for use with a split taper bushing and accommodates a 1-inch belt width, identified by manufacturer part number 20LG100.

Frequently Asked Questions

What is the APPROVED VENDOR Timing Belt Pulley 20LG100 used for?

The APPROVED VENDOR Timing Belt Pulley 20LG100 is used in power transmission systems to synchronize rotational motion. It is designed for L-section timing belts with a 1-inch belt width and works with a split taper bushing, making it suitable for industrial machinery, conveyors, and automation equipment.

What are the specifications of the APPROVED VENDOR Timing Belt Pulley 20LG100?

The APPROVED VENDOR Timing Belt Pulley 20LG100 features a trapezoidal tooth profile, black oxide finish, and is designed for use with a split taper bushing. It accommodates L-section timing belts with a 1-inch belt width. The manufacturer part number is 20LG100.

Where to buy the APPROVED VENDOR Timing Belt Pulley 20LG100 worldwide?

You can source the APPROVED VENDOR Timing Belt Pulley 20LG100 through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring the pulley reaches your facility reliably.

How to select the correct bushing for the APPROVED VENDOR Timing Belt Pulley 20LG100?

To select the correct bushing for the APPROVED VENDOR Timing Belt Pulley 20LG100, choose a split taper bushing that matches the pulley's bore size and shaft diameter. Ensure the bushing's keyway and set screw align with the pulley's design for secure mounting and proper power transmission.
