APPROVED VENDOR Timing Belt Pulley: Trapezoidal, Bushed, For H Timing Belt Section - Bushed H Section Timing Belt Pulleys
APPROVED VENDORBushed H Section Timing Belt Pulleys

APPROVED VENDOR Timing Belt Pulley: Trapezoidal, Bushed, For H Timing Belt Section

The APPROVED VENDOR Timing Belt Pulley is a bushed H section trapezoidal timing belt pulley with a black oxide finish. It is designed for use with a split taper bushing and accommodates a 1-inch belt width (MPN 24HP100).

SKU 3G-OTH-107742

Brand
APPROVED VENDOR
Item
Timing Belt Pulley: Trapezoidal, Bushed, For H Timing Belt Section
Category
Bushed H Section Timing Belt Pulleys
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
24HP100
Type
Bushed, For H Timing Belt Section, For 1 in Belt Wd
Finish
Black Oxide
Tooth Profile
Trapezoidal
For Bushing Type
Split Taper
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Timing Belt Pulley is a bushed H section trapezoidal timing belt pulley with a black oxide finish. It is designed for use with a split taper bushing and accommodates a 1-inch belt width (MPN 24HP100).

Frequently Asked Questions

What is the APPROVED VENDOR Timing Belt Pulley used for?

The APPROVED VENDOR Timing Belt Pulley is used in industrial power transmission systems to synchronize rotational motion. It is designed for H-section timing belts with a 1-inch belt width, making it suitable for conveyors, packaging machinery, and automated equipment requiring precise timing and reduced slippage.

What are the specifications of the APPROVED VENDOR Timing Belt Pulley 24HP100?

The APPROVED VENDOR Timing Belt Pulley 24HP100 features a trapezoidal tooth profile, black oxide finish, and is designed for split taper bushings. It accommodates H-section timing belts with a 1-inch belt width. The bushed design allows secure mounting on shafts using a split taper bushing system.

Where to buy the APPROVED VENDOR Timing Belt Pulley worldwide?

You can source the APPROVED VENDOR Timing Belt Pulley through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this bushed H-section pulley.

How to select the correct bushing for the APPROVED VENDOR Timing Belt Pulley?

Select a split taper bushing that matches the shaft diameter and the pulley's bore size. The APPROVED VENDOR pulley is designed for split taper bushings, which provide a tight, concentric grip. Ensure the bushing keyway aligns with the shaft key for secure torque transmission. Consult the pulley's specifications for compatible bushing series.
