APPROVED VENDOR Timing Belt Pulley: Trapezoidal, Bushed, For H Timing Belt Section - Bushed H Section Timing Belt Pulleys
APPROVED VENDORBushed H Section Timing Belt Pulleys

APPROVED VENDOR Timing Belt Pulley: Trapezoidal, Bushed, For H Timing Belt Section

The APPROVED VENDOR Timing Belt Pulley is a bushed H section trapezoidal timing belt pulley with a black oxide finish. It is designed for use with quick detachable bushings and accommodates H section timing belts…

SKU 3G-OTH-107182

Brand
APPROVED VENDOR
Item
Timing Belt Pulley: Trapezoidal, Bushed, For H Timing Belt Section
Category
Bushed H Section Timing Belt Pulleys
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
QD120H100
Type
Bushed, For H Timing Belt Section, For 1 in Belt Wd
Finish
Black Oxide
Tooth Profile
Trapezoidal
For Bushing Type
Quick Detachable
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The APPROVED VENDOR Timing Belt Pulley is a bushed H section trapezoidal timing belt pulley with a black oxide finish. It is designed for use with quick detachable bushings and accommodates H section timing belts with a 1-inch belt width. The manufacturer part number is QD120H100.

Frequently Asked Questions

What is the APPROVED VENDOR Timing Belt Pulley QD120H100 used for?

This trapezoidal timing belt pulley is used in industrial power transmission systems to synchronize motion with H section timing belts. It is commonly applied in conveyor drives, packaging machinery, and automated equipment where precise timing and positive drive are required.

What are the specifications of the APPROVED VENDOR Timing Belt Pulley QD120H100?

The pulley has a trapezoidal tooth profile, black oxide finish, and is designed for quick detachable bushings. It accommodates H section timing belts with a 1-inch belt width. The manufacturer part number is QD120H100, and it is supplied by APPROVED VENDOR.

Where to buy the APPROVED VENDOR Timing Belt Pulley QD120H100 worldwide?

3G Electric supplies the APPROVED VENDOR Timing Belt Pulley QD120H100 to customers worldwide. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this bushed H section pulley.

How to select the correct bushing for the APPROVED VENDOR Timing Belt Pulley QD120H100?

Select a quick detachable bushing that matches the pulley's bore size and shaft diameter. Ensure the bushing keyway and set screw align with your shaft. Refer to the bushing manufacturer's catalog for proper fit. The pulley is designed specifically for quick detachable bushings.
