APPROVED VENDOR Helical Inserts: Tanged Tang Style, Free-Running, M18x2.5 Thread Size - Free-Running Tanged Helical Inserts
APPROVED VENDORFree-Running Tanged Helical Inserts

APPROVED VENDOR Helical Inserts: Tanged Tang Style, Free-Running, M18x2.5 Thread Size

APPROVED VENDOR Helical Inserts are free-running, tanged tang style inserts with M18x2.5 thread size, right-hand coarse metric threads, made from 304 chromium nickel metal with a length of 15.5 mm and tensile…

SKU 3G-OTH-599202

Brand
APPROVED VENDOR
Item
Helical Inserts: Tanged Tang Style, Free-Running, M18x2.5 Thread Size
Category
Free-Running Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

APPROVED VENDOR
Manufacturer Part Number
5WZR7
Type
Free-Running, M18x2.5 Thread Size, 5 PK
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

APPROVED VENDOR Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

APPROVED VENDOR Helical Inserts are free-running, tanged tang style inserts with M18x2.5 thread size, right-hand coarse metric threads, made from 304 chromium nickel metal with a length of 15.5 mm and tensile strength of 200,000 psi, sold in a 5-pack (MPN 5WZR7).

Frequently Asked Questions

What are APPROVED VENDOR helical inserts used for?

APPROVED VENDOR helical inserts repair or reinforce tapped threads in metal assemblies. The free-running tanged tang style with M18x2.5 coarse metric threads suits high-stress applications across machining, power transmission, and industrial equipment where thread strength is critical.

What are the specifications of APPROVED VENDOR M18x2.5 helical inserts?

These free-running tanged inserts have M18x2.5 right-hand coarse metric threads, 15.5 mm length, made from 304 chromium nickel metal with 200,000 psi tensile strength. Sold in a 5-pack (MPN 5WZR7). They are designed for metal substrates and metric thread systems.

Where to buy APPROVED VENDOR helical inserts worldwide?

3G Electric supplies APPROVED VENDOR helical inserts worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us to order the M18x2.5 5-pack (MPN 5WZR7) for your thread repair needs.

How to install APPROVED VENDOR tanged helical inserts?

Installation requires drilling to the specified tap drill size, tapping with the correct STI tap, then winding the insert using a tang drive tool. After insertion, break off the tang with a punch. Always follow the manufacturer's torque and depth guidelines for the M18x2.5 coarse thread.
