ARCHON INDUSTRIES, INC. Single Wall Sight Flow Indicator: Plain, Stainless Steel

The ARCHON INDUSTRIES, INC. AKF-FP020AC07A is a single wall sight flow indicator (flow sight) designed for fluid media. It features a 2-inch flange connection, a borosilicate glass sight, stainless steel bolts, and a…

SKU 3G-OTH-90955

Brand

ARCHON INDUSTRIES, INC.

Item

Single Wall Sight Flow Indicator: Plain, Stainless Steel

Technical Specifications

ARCHON INDUSTRIES, INC.

Manufacturer Part Number

AKF-FP020AC07A

Type

Stainless Steel, PTFE

Flange

2 in

Bolt Material

Stainless Steel

Seal Material

PTFE

Flow Direction

Horizontal Left

For Media Type

Fluids

Sight Material

Borosilicate Glass

Connection Type

Flange

INC. Single Wall Sight Flow Indicator

Plain

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

ARCHON INDUSTRIES, INC. Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Frequently Asked Questions

What is the ARCHON INDUSTRIES AKF-FP020AC07A sight flow indicator used for?

The ARCHON INDUSTRIES AKF-FP020AC07A is a single wall sight flow indicator used to visually verify fluid flow in piping systems. It is commonly applied in industrial process lines, cooling circuits, and lubrication systems where confirming flow direction and media presence is critical.

What are the specifications of the ARCHON AKF-FP020AC07A flow sight?

The ARCHON AKF-FP020AC07A has a 2 in flange connection, borosilicate glass sight, stainless steel bolts, and a PTFE seal. It is designed for fluid media with horizontal left flow direction. The body is stainless steel. 3G Electric supplies this genuine ARCHON part worldwide.

Where to buy the ARCHON AKF-FP020AC07A sight flow indicator worldwide?

3G Electric supplies the ARCHON AKF-FP020AC07A sight flow indicator to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote and lead time on this genuine ARCHON part.

How to install the ARCHON AKF-FP020AC07A sight flow indicator?

Install the ARCHON AKF-FP020AC07A by bolting the 2 in flange connections to matching pipe flanges using appropriate gaskets. Ensure flow direction matches the horizontal left marking. Tighten bolts evenly to avoid glass stress. 3G Electric can provide sourcing support for this ARCHON flow sight.

Used in

Common applications for ARCHON INDUSTRIES, INC.

Food and beverage processing — Sanitary full-view flow indicators (e.g., AKGCL10-C19A0A) for visual monitoring of liquid flow in stainless steel piping.

Chemical transfer systems — Single-wall sight flow indicators with PTFE seals (e.g., AKF-FP020AC07A) for corrosive fluid observation.

Steam and hot water lines — Gauge valves (e.g., TV55-7/07TA02N) for level indication on boiler drums or tanks up to 500°F.

Pharmaceutical manufacturing — Sanitary flow indicators with silicone seals (e.g., AKGCL20-C06A0A) for clean-in-place (CIP) systems.

Water treatment plants — Plain steel flow sights (e.g., AKF-FP005AA05A) for monitoring flow in filtration or distribution lines.

Oil and gas auxiliary systems — Flanged flow indicators (e.g., AKF-FP010AA05A) for visual check of lubricating oil or coolant flow.
