ASHCROFT Pressure Transmitter: 0 psi to 5,000 psi, 4 to 20mA DC, Hirschmann Form A DIN 43650-A
The ASHCROFT A4 Series Intrinsically Safe-Rated Transmitter (SKU 5DDG2) is a gauge pressure transmitter with a 0 psi to 5,000 psi range and a 4 to 20mA DC output. It features a stainless steel housing, an IP65 / NEMA…
SKU 3G-OTH-176577
Need installation or engineering help?
Ask a question
Product Description
The ASHCROFT A4 Series Intrinsically Safe-Rated Transmitter (SKU 5DDG2) is a gauge pressure transmitter with a 0 psi to 5,000 psi range and a 4 to 20mA DC output. It features a stainless steel housing, an IP65 / NEMA 4X rating, and a Hirschmann® Form A DIN 43650-A electrical connection. The unit is rated Class II, Div 1 and 2, Group F, G, with an accuracy of ±0.50% of Full Scale, overpressure of 1.2x Range, and burst pressure of 1.5x Range. A NIST-Traceable Calibration Certificate is included.
Frequently Asked Questions
What is the ASHCROFT A4 Series pressure transmitter used for?
The ASHCROFT A4 Series intrinsically safe pressure transmitter is used for gauge pressure measurement in hazardous industrial environments. It is suitable for applications requiring Class II, Div 1 and 2, Group F, G safety ratings, such as oil and gas, chemical processing, and power generation.
What are the specifications of the ASHCROFT A4 pressure transmitter?
The ASHCROFT A4 transmitter (MPN A4SBM0242D05000#) has a 0 psi to 5,000 psi range, 4 to 20mA DC output, and ±0.50% of Full Scale accuracy. It features a stainless steel housing, IP65/NEMA 4X rating, Hirschmann® Form A DIN 43650-A connection, and NPT process connection. Overpressure is 1.2x Range, burst pressure 1.5x Range.
Where to buy the ASHCROFT A4 pressure transmitter worldwide?
You can source the ASHCROFT A4 pressure transmitter worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we provide NIST-traceable calibration certificates with each unit.
How to install the ASHCROFT A4 intrinsically safe transmitter?
Install the ASHCROFT A4 transmitter by connecting the NPT process connection to the system, ensuring proper sealing. Wire the 4 to 20mA DC output to the Hirschmann® Form A DIN 43650-A connector per the wiring diagram. For intrinsically safe installations, follow applicable hazardous area wiring practices and verify the IP65/NEMA 4X seal integrity.
