ASHCROFT Pressure Transmitter: 0 psi to 15 psi, 4 to 20mA DC, Hirschmann Form A DIN 43650-A
The ASHCROFT A4 Series Pressure Transmitter (0 psi to 15 psi) is an intrinsically safe-rated gauge transmitter with a 4 to 20mA DC output and ±0.50% of Full Scale accuracy. It features a stainless steel housing, IP65…
SKU 3G-OTH-176554
Need installation or engineering help?
Ask a question
Product Description
The ASHCROFT A4 Series Pressure Transmitter (0 psi to 15 psi) is an intrinsically safe-rated gauge transmitter with a 4 to 20mA DC output and ±0.50% of Full Scale accuracy. It features a stainless steel housing, IP65 and NEMA 4X ratings, a Hirschmann® Form A DIN 43650-A electrical connection, and an NPT process connection. The transmitter is rated Class II, Div 1 and 2, Group F, G, with overpressure of 1.5x range and burst pressure of 2x range, and includes a NIST-traceable calibration certificate.
Frequently Asked Questions
What is the ASHCROFT A4 Series pressure transmitter used for?
The ASHCROFT A4 Series pressure transmitter is used for industrial gauge pressure measurement in hazardous environments. It is suitable for applications requiring intrinsic safety, such as oil and gas, chemical processing, and power generation, where reliable 4 to 20mA DC output and NEMA 4X/IP65 protection are needed.
What are the specifications of the ASHCROFT A4 pressure transmitter 0 to 15 psi?
The ASHCROFT A4 transmitter measures 0 psi to 15 psi gauge with ±0.50% of Full Scale accuracy. It has a 4 to 20mA DC output, stainless steel housing, IP65 and NEMA 4X ratings, Hirschmann® Form A DIN 43650-A connector, NPT process connection, and is intrinsically safe rated Class II, Div 1 and 2, Group F, G.
Where to buy the ASHCROFT A4 pressure transmitter worldwide?
You can source the ASHCROFT A4 pressure transmitter through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we provide NIST-traceable calibration certificates with each unit.
How to install the ASHCROFT A4 intrinsically safe pressure transmitter?
Install the ASHCROFT A4 transmitter by connecting the NPT process connection to the system, ensuring proper sealing. Wire the 4 to 20mA DC output to the Hirschmann® Form A DIN 43650-A connector per the wiring diagram. For hazardous locations, follow intrinsic safety barrier requirements and local codes. Calibrate using the NIST-traceable certificate.
Used in
Common applications for ASHCROFTASHCROFT Products
3G Electric supplies ASHCROFT intrinsically safe with din 43650 form a connector. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
