ASHCROFT Pressure Transmitter: 0 psi to 1,000 psi, 4 to 20mA DC, Hirschmann Form A DIN 43650-A
The ASHCROFT A4 Series Intrinsically Safe-Rated Transmitter (SKU 5DDH2) measures gauge pressure from 0 psi to 1,000 psi with a 4 to 20mA DC output and ±0.25% of full scale accuracy. It features a stainless steel…
SKU 3G-OTH-176572
Need installation or engineering help?
Ask a question
Product Description
The ASHCROFT A4 Series Intrinsically Safe-Rated Transmitter (SKU 5DDH2) measures gauge pressure from 0 psi to 1,000 psi with a 4 to 20mA DC output and ±0.25% of full scale accuracy. It features a stainless steel housing, IP65 and NEMA 4X ratings, a Hirschmann® Form A DIN 43650-A electrical connection, and an NPT process connection. The transmitter is rated Class III, Div 1 and 2 for intrinsically safe applications, with overpressure of 1.2x range and burst pressure of 1.5x range, and includes a NIST-Traceable Calibration Certificate.
Frequently Asked Questions
What is the ASHCROFT A4 pressure transmitter used for?
The ASHCROFT A4 intrinsically safe pressure transmitter is used for gauge pressure measurement from 0 psi to 1,000 psi in hazardous industrial environments. It is suitable for Class III, Div 1 and 2 locations, providing a 4 to 20mA DC output with ±0.25% accuracy. Typical applications include oil and gas, chemical processing, and water treatment where safety and reliability are critical.
What are the specifications of the ASHCROFT A4 pressure transmitter?
The ASHCROFT A4 transmitter (MPN A4BCM0442D01000#) measures 0 psi to 1,000 psi gauge pressure with 4 to 20mA DC output and ±0.25% accuracy. It features a stainless steel housing, IP65 and NEMA 4X ratings, Hirschmann® Form A DIN 43650-A electrical connection, and NPT process connection. Overpressure is 1.2x range, burst pressure 1.5x range, and it includes a NIST-Traceable Calibration Certificate.
Where to buy the ASHCROFT A4 pressure transmitter worldwide?
You can source the ASHCROFT A4 pressure transmitter worldwide through 3G Electric, a global industrial equipment distributor established in 1990. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time. 3G Electric provides reliable sourcing for this intrinsically safe transmitter with Hirschmann® connector.
How to install the ASHCROFT A4 intrinsically safe pressure transmitter?
Install the ASHCROFT A4 transmitter by connecting the NPT process connection to the system using appropriate sealant. Wire the 4 to 20mA DC output to the Hirschmann® Form A DIN 43650-A connector per the wiring diagram. Ensure the installation meets Class III, Div 1 and 2 intrinsic safety requirements. Avoid exceeding 1.2x range overpressure. Calibrate using the included NIST-Traceable Certificate.
