ASHCROFT Pressure Transmitter: 0 psi to 500 psi, 4 to 20mA DC, Hirschmann Form A DIN 43650-A
The ASHCROFT A4 Series Pressure Transmitter (0 psi to 500 psi) is an intrinsically safe-rated transmitter with a 4 to 20mA DC output and a Hirschmann® Form A DIN 43650-A connector. It features a stainless steel…
SKU 3G-OTH-176590
Need installation or engineering help?
Ask a question
Product Description
The ASHCROFT A4 Series Pressure Transmitter (0 psi to 500 psi) is an intrinsically safe-rated transmitter with a 4 to 20mA DC output and a Hirschmann® Form A DIN 43650-A connector. It features a stainless steel housing, IP65 and NEMA 4X ratings, and a gauge pressure type with an NPT process connection. Accuracy is ±0.50% of full scale, with overpressure of 1.2x range and burst pressure of 1.5x range. A NIST-traceable calibration certificate is included.
Frequently Asked Questions
What is the ASHCROFT A4 pressure transmitter used for?
The ASHCROFT A4 Series pressure transmitter is used for industrial pressure measurement in hazardous environments requiring intrinsic safety. It is suitable for applications in oil and gas, chemical processing, and water treatment where a 4 to 20mA DC output and NPT process connection are needed.
What are the specifications of the ASHCROFT A4 pressure transmitter?
The ASHCROFT A4 transmitter measures 0 psi to 500 psi gauge pressure with ±0.50% full-scale accuracy. It has a 4 to 20mA DC output, stainless steel housing, IP65 and NEMA 4X ratings, and a Hirschmann® Form A DIN 43650-A connector. Overpressure is 1.2x range; burst pressure is 1.5x range.
Where to buy the ASHCROFT A4 pressure transmitter worldwide?
You can source the ASHCROFT A4 pressure transmitter through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this intrinsically safe transmitter.
How to install the ASHCROFT A4 pressure transmitter?
Install the ASHCROFT A4 transmitter by connecting the NPT process connection to the system using appropriate sealant. Wire the 4 to 20mA DC output to the Hirschmann® Form A DIN 43650-A connector per the wiring diagram. Ensure the installation meets intrinsic safety requirements for Class III, Div 1 and 2 areas.
