ASHCROFT Pressure Transmitter: -15 psi to 30 psi, 4 to 20mA DC, 4-Pin M12 Connector - Pressure Transmitters with 4-Pin M12 Connector
ASHCROFTPressure Transmitters with 4-Pin M12 Connector

ASHCROFT Pressure Transmitter: -15 psi to 30 psi, 4 to 20mA DC, 4-Pin M12 Connector

The ASHCROFT G2 Series Pressure Transmitter with 4-Pin M12 Connector (SKU 5DDZ3) measures -15 psi to 30 psi with a 4 to 20mA DC output and ±0.5% accuracy. It features a nylon housing, IP67 and NEMA 4X ratings…

SKU 3G-OTH-176713

Brand
ASHCROFT
Item
Pressure Transmitter: -15 psi to 30 psi, 4 to 20mA DC, 4-Pin M12 Connector
Category
Pressure Transmitters with 4-Pin M12 Connector
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
G17MEK42EWVAC/30#
Series
G2
DC
4 to 20mA
Output
4 to 20mA DC
Accuracy
±0.5%
Male SAE
7/16 in
IP Rating
IP67
NEMA Rating
4X
Overpressure
2x Range
M12 Connector
4-Pin
Burst Pressure
10x Range
Pressure Range
-15 psi to 30 psi
Housing Material
Nylon
Process Connection Type
SAE
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT G2 Series Pressure Transmitter with 4-Pin M12 Connector (SKU 5DDZ3) measures -15 psi to 30 psi with a 4 to 20mA DC output and ±0.5% accuracy. It features a nylon housing, IP67 and NEMA 4X ratings, overpressure of 2x Range, burst pressure of 10x Range, and a 7/16 in Male SAE process connection. No NIST-Traceable Calibration Certificate is included.

Frequently Asked Questions

What is the ASHCROFT G2 pressure transmitter used for?

The ASHCROFT G2 pressure transmitter measures -15 psi to 30 psi with a 4 to 20mA DC output, making it suitable for industrial pressure monitoring in hydraulic systems, compressors, and process equipment requiring IP67 and NEMA 4X environmental protection.

What are the specifications of the ASHCROFT G17MEK42EWVAC/30# pressure transmitter?

This ASHCROFT G2 transmitter has ±0.5% accuracy, 4 to 20mA DC output, 4-pin M12 connector, 7/16 in male SAE connection, nylon housing, IP67 and NEMA 4X ratings, overpressure 2x range, burst pressure 10x range, and no NIST-traceable calibration certificate included.

Where to buy the ASHCROFT G2 pressure transmitter worldwide?

3G Electric supplies the ASHCROFT G2 pressure transmitter (SKU 5DDZ3) worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to select the right ASHCROFT pressure transmitter for my application?

Select based on pressure range (-15 to 30 psi), output signal (4 to 20mA DC), process connection (7/16 in male SAE), and environmental ratings (IP67/NEMA 4X). Verify media compatibility with the nylon housing and confirm overpressure (2x range) and burst pressure (10x range) meet system safety requirements.

Used in

Common applications for ASHCROFT
Process control in chemical plants — ASHCROFT G2 series pressure transmitters with 4-20 mA output
Sanitary monitoring in food processing — ASHCROFT sanitary pressure transmitters with stainless steel fittings
Temperature measurement in oil and gas — ASHCROFT flanged thermowells rated to 1,000°F
Hydraulic system pressure monitoring — ASHCROFT G2 series transmitters with 1-5 V DC output
Hazardous location pressure sensing — ASHCROFT A2X explosion-proof transmitters with conduit connection
Steam system temperature protection — ASHCROFT threaded thermowells rated to 7,000 psi
