ASHCROFT Pressure Transmitter: 0 psi to 7,500 psi, 4 to 20mA DC, 4-Pin M12 Connector - Pressure Transmitters with 4-Pin M12 Connector
ASHCROFTPressure Transmitters with 4-Pin M12 Connector

ASHCROFT Pressure Transmitter: 0 psi to 7,500 psi, 4 to 20mA DC, 4-Pin M12 Connector

The ASHCROFT G2 Series Pressure Transmitter (SKU 5DEA3) is a 0 psi to 7,500 psi pressure transmitter with a 4-Pin M12 Connector and a 4 to 20mA DC output. It features ±0.5% accuracy, an IP67 and NEMA 4X rating, a…

SKU 3G-OTH-176734

Brand
ASHCROFT
Item
Pressure Transmitter: 0 psi to 7,500 psi, 4 to 20mA DC, 4-Pin M12 Connector
Category
Pressure Transmitters with 4-Pin M12 Connector
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
G17MEK42EW7500#
Series
G2
DC
4 to 20mA
Output
4 to 20mA DC
Accuracy
±0.5%
Male SAE
7/16 in
IP Rating
IP67
NEMA Rating
4X
Overpressure
1.5x Range
M12 Connector
4-Pin
Burst Pressure
5x Range
Housing Material
Nylon
Process Connection Type
SAE
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT G2 Series Pressure Transmitter (SKU 5DEA3) is a 0 psi to 7,500 psi pressure transmitter with a 4-Pin M12 Connector and a 4 to 20mA DC output. It features ±0.5% accuracy, an IP67 and NEMA 4X rating, a nylon housing, and a 7/16 in Male SAE process connection. Overpressure capability is 1.5x range, with burst pressure at 5x range.

Frequently Asked Questions

What is the ASHCROFT G2 pressure transmitter used for?

The ASHCROFT G2 pressure transmitter measures pressure from 0 psi to 7,500 psi in industrial hydraulic and pneumatic systems. It is suitable for applications requiring a 4 to 20mA DC output, IP67/NEMA 4X protection, and a 7/16 in Male SAE connection.

What are the specifications of the ASHCROFT G2 pressure transmitter?

The ASHCROFT G2 (MPN G17MEK42EW7500#) has ±0.5% accuracy, 4 to 20mA DC output, IP67 and NEMA 4X ratings, nylon housing, 7/16 in Male SAE connection, overpressure 1.5x range, and burst pressure 5x range. No NIST-traceable calibration certificate is included.

Where to buy the ASHCROFT G2 pressure transmitter worldwide?

3G Electric supplies the ASHCROFT G2 pressure transmitter worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to select the ASHCROFT G2 pressure transmitter for my system?

Select the ASHCROFT G2 based on your pressure range (0 to 7,500 psi), output signal (4 to 20mA DC), process connection (7/16 in Male SAE), and environmental rating (IP67/NEMA 4X). Ensure the overpressure (1.5x range) and burst pressure (5x range) meet your system safety requirements.

Used in

Common applications for ASHCROFT
Process control in chemical plants — ASHCROFT G2 series pressure transmitters with 4-20 mA output
Sanitary monitoring in food processing — ASHCROFT sanitary pressure transmitters with stainless steel fittings
Temperature measurement in oil and gas — ASHCROFT flanged thermowells rated to 1,000°F
Hydraulic system pressure monitoring — ASHCROFT G2 series transmitters with 1-5 V DC output
Hazardous location pressure sensing — ASHCROFT A2X explosion-proof transmitters with conduit connection
Steam system temperature protection — ASHCROFT threaded thermowells rated to 7,000 psi

ASHCROFT Products

3G Electric supplies ASHCROFT pressure transmitters with 4-pin m12 connector. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
