ASHCROFT Pressure Transmitter: 0 psi to 500 psi, 4 to 20mA DC - Pressure Transmitters with 4-Pin Mini-DIN Connector
ASHCROFTPressure Transmitters with 4-Pin Mini-DIN Connector

ASHCROFT Pressure Transmitter: 0 psi to 500 psi, 4 to 20mA DC

The ASHCROFT G2 Series Pressure Transmitter (0 psi to 500 psi) is a pressure transmitter with a 4-Pin Mini-DIN connector, featuring a 4 to 20mA DC output. It offers ±0.5% accuracy, an IP67 and NEMA 4X rating, and a…

SKU 3G-OTH-176251

Brand
ASHCROFT
Item
Pressure Transmitter: 0 psi to 500 psi, 4 to 20mA DC
Category
Pressure Transmitters with 4-Pin Mini-DIN Connector
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
G17M0242M1500#
Series
G2
Type
4-Pin Mini-DIN Hirschmann G Series Connector
DC
4 to 20mA
Output
4 to 20mA DC
Accuracy
±0.5%
IP Rating
IP67
NEMA Rating
4X
Overpressure
2x Range
Burst Pressure
10x Range
Housing Material
Nylon
Process Connection Type
NPT
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT G2 Series Pressure Transmitter (0 psi to 500 psi) is a pressure transmitter with a 4-Pin Mini-DIN connector, featuring a 4 to 20mA DC output. It offers ±0.5% accuracy, an IP67 and NEMA 4X rating, and a nylon housing with a male NPT process connection. Overpressure capability is 2x range, with a burst pressure of 10x range.

Frequently Asked Questions

What is the ASHCROFT G2 pressure transmitter used for?

The ASHCROFT G2 pressure transmitter measures pressure from 0 psi to 500 psi and outputs a 4 to 20mA DC signal. It is used in industrial process control, hydraulic systems, and pump monitoring where a rugged, NEMA 4X and IP67-rated nylon housing is required.

What are the specifications of the ASHCROFT G2 pressure transmitter?

The ASHCROFT G2 pressure transmitter (MPN G17M0242M1500#) has an accuracy of ±0.5%, a 4 to 20mA DC output, IP67 and NEMA 4X ratings, overpressure of 2x range, burst pressure of 10x range, a nylon housing, and a male NPT process connection. No NIST-traceable calibration certificate is included.

Where to buy the ASHCROFT G2 pressure transmitter worldwide?

3G Electric supplies the ASHCROFT G2 pressure transmitter worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this model.

How to select the ASHCROFT G2 pressure transmitter for an application?

Select the ASHCROFT G2 pressure transmitter by verifying the pressure range (0 psi to 500 psi), output (4 to 20mA DC), and process connection (male NPT). Ensure the IP67 and NEMA 4X ratings suit the environment. For corrosive media, confirm compatibility with the nylon housing.
