ASHCROFT Pressure Transmitter: -15 psi to 30 psi, 4 to 20mA DC - Pressure Transmitters with 4-Pin Mini-DIN Connector
ASHCROFTPressure Transmitters with 4-Pin Mini-DIN Connector

ASHCROFT Pressure Transmitter: -15 psi to 30 psi, 4 to 20mA DC

The ASHCROFT G2 Pressure Transmitter with 4-Pin Mini-DIN Connector (SKU 5DEH9) measures -15 psi to 30 psi with a 4 to 20mA DC output and ±0.5% accuracy. It features an IP67 and NEMA 4X rating, nylon housing, SAE male…

SKU 3G-OTH-176259

Brand
ASHCROFT
Item
Pressure Transmitter: -15 psi to 30 psi, 4 to 20mA DC
Category
Pressure Transmitters with 4-Pin Mini-DIN Connector
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
G17MEK42M1VAC/30#
Series
G2
Type
4-Pin Mini-DIN Hirschmann G Series Connector
DC
4 to 20mA
Output
4 to 20mA DC
Accuracy
±0.5%
IP Rating
IP67
NEMA Rating
4X
Overpressure
2x Range
Burst Pressure
10x Range
Pressure Range
-15 psi to 30 psi
Housing Material
Nylon
Process Connection Type
SAE
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT G2 Pressure Transmitter with 4-Pin Mini-DIN Connector (SKU 5DEH9) measures -15 psi to 30 psi with a 4 to 20mA DC output and ±0.5% accuracy. It features an IP67 and NEMA 4X rating, nylon housing, SAE male process connection, overpressure of 2x range, and burst pressure of 10x range. No NIST-traceable calibration certificate is included.

Frequently Asked Questions

What is the ASHCROFT G2 pressure transmitter used for?

The ASHCROFT G2 pressure transmitter measures pressure from -15 psi to 30 psi in industrial applications requiring a 4 to 20mA DC output. Its IP67 and NEMA 4X ratings make it suitable for wet or corrosive environments, such as hydraulic systems, water treatment, and process control.

What are the specifications of the ASHCROFT G2 pressure transmitter?

The ASHCROFT G2 (MPN G17MEK42M1VAC/30#) has a pressure range of -15 psi to 30 psi, ±0.5% accuracy, 4 to 20mA DC output, IP67 and NEMA 4X ratings, nylon housing, SAE male process connection, overpressure of 2x range, and burst pressure of 10x range. No NIST-traceable calibration certificate is included.

Where to buy the ASHCROFT G2 pressure transmitter worldwide?

3G Electric supplies the ASHCROFT G2 pressure transmitter worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this model.

How to select the ASHCROFT G2 pressure transmitter for an application?

To select the ASHCROFT G2, verify the pressure range (-15 psi to 30 psi), output signal (4 to 20mA DC), and process connection (SAE male). Ensure the IP67 and NEMA 4X ratings match the environmental exposure. Confirm overpressure (2x range) and burst pressure (10x range) exceed system demands.

Used in

Common applications for ASHCROFT
Process control in chemical plants — ASHCROFT G2 series pressure transmitters with 4-20 mA output
Sanitary monitoring in food processing — ASHCROFT sanitary pressure transmitters with stainless steel fittings
Temperature measurement in oil and gas — ASHCROFT flanged thermowells rated to 1,000°F
Hydraulic system pressure monitoring — ASHCROFT G2 series transmitters with 1-5 V DC output
Hazardous location pressure sensing — ASHCROFT A2X explosion-proof transmitters with conduit connection
Steam system temperature protection — ASHCROFT threaded thermowells rated to 7,000 psi

ASHCROFT Products

3G Electric supplies ASHCROFT pressure transmitters with 4-pin mini-din connector. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
