ASHCROFT Pressure Transmitter: 0 psi to 3,000 psi, 1 to 5V DC, Cable & Wire Leads
The ASHCROFT A2X Series Explosion-Proof-Rated Transmitter (SKU 5LRH5) is a gauge pressure transmitter with a 0 psi to 3,000 psi range and a 1 to 5V DC output. It features a stainless steel housing, NPT process…
SKU 3G-OTH-175474
Need installation or engineering help?
Ask a question
Product Description
The ASHCROFT A2X Series Explosion-Proof-Rated Transmitter (SKU 5LRH5) is a gauge pressure transmitter with a 0 psi to 3,000 psi range and a 1 to 5V DC output. It features a stainless steel housing, NPT process connection, and IP65/NEMA 4X ratings. The unit is rated Class I, Div 1 and 2, Group A, B, C, D, with ±0.50% of Full Scale accuracy, overpressure of 1.2x Range, and burst pressure of 1.5x Range. A NIST-Traceable Calibration Certificate is included.
Frequently Asked Questions
What is the ASHCROFT A2X pressure transmitter used for?
The ASHCROFT A2X explosion-proof-rated transmitter is used for gauge pressure measurement in hazardous industrial environments. It is suitable for applications requiring Class I, Div 1 and 2, Group A, B, C, D safety ratings, such as oil and gas, chemical processing, and refineries.
What are the specifications of the ASHCROFT A2X pressure transmitter?
The ASHCROFT A2X transmitter has a 0 psi to 3,000 psi range, 1 to 5V DC output, ±0.50% of Full Scale accuracy, and stainless steel housing. It features NPT process connection, IP65/NEMA 4X ratings, overpressure of 1.2x Range, and burst pressure of 1.5x Range. A NIST-Traceable Calibration Certificate is included.
Where to buy the ASHCROFT A2X pressure transmitter worldwide?
3G Electric supplies the ASHCROFT A2X pressure transmitter worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this explosion-proof-rated transmitter.
How to install the ASHCROFT A2X explosion-proof transmitter?
Install the ASHCROFT A2X transmitter by connecting the NPT process connection to the system, ensuring proper sealing. Wire the 1 to 5V DC output via the conduit connection with wire leads. Follow standard hazardous-area installation practices for Class I, Div 1 and 2 environments. Always consult the manufacturer's manual for torque and wiring details.
