ASHCROFT Pressure Transmitter: 0 psi to 1,000 psi, 1 to 5V DC, Cable & Wire Leads
The ASHCROFT A2X Series Pressure Transmitter (SKU 5LRJ6) is an explosion-proof-rated transmitter with a conduit connection and wire leads, measuring gauge pressure from 0 psi to 1,000 psi. It provides a 1 to 5V DC…
SKU 3G-OTH-175390
Need installation or engineering help?
Ask a question
Product Description
The ASHCROFT A2X Series Pressure Transmitter (SKU 5LRJ6) is an explosion-proof-rated transmitter with a conduit connection and wire leads, measuring gauge pressure from 0 psi to 1,000 psi. It provides a 1 to 5V DC output, features a stainless steel housing with IP65 and NEMA 7 ratings, and includes a NIST-traceable calibration certificate. The transmitter has an accuracy of ±0.50% of full scale, overpressure of 1.2x range, and burst pressure of 1.5x range, with a Class II, Div 1 and 2, Group E, F, G safety rating.
Frequently Asked Questions
What is the ASHCROFT A2X pressure transmitter used for?
The ASHCROFT A2X Series pressure transmitter is used for measuring gauge pressure in hazardous industrial environments. Its explosion-proof rating (Class II, Div 1 and 2, Group E, F, G) and NEMA 7 enclosure make it suitable for applications in oil and gas, chemical processing, and grain handling where combustible dust or gases are present.
What are the specifications of the ASHCROFT A2X pressure transmitter?
The ASHCROFT A2X transmitter (MPN A2XBF0215C21000#G) measures 0 psi to 1,000 psi gauge pressure with ±0.50% full-scale accuracy. It outputs 1 to 5V DC, has a stainless steel housing rated IP65/NEMA 7, NPT process connection, overpressure of 1.2x range, burst pressure of 1.5x range, and includes a NIST-traceable calibration certificate.
Where to buy the ASHCROFT A2X pressure transmitter worldwide?
3G Electric supplies the ASHCROFT A2X pressure transmitter worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time. We source and deliver this explosion-proof transmitter to any country.
How to install the ASHCROFT A2X pressure transmitter?
Install the ASHCROFT A2X transmitter by connecting the NPT process connection to the system using appropriate sealant. Wire the 1 to 5V DC output via the conduit connection and wire leads per the wiring diagram. Ensure the enclosure is properly sealed to maintain IP65/NEMA 7 integrity. Follow ASHCROFT's installation manual for hazardous-location requirements.
