ASHCROFT Pressure Transmitter: 0 psi to 60 psi, 1 to 5V DC, Cable & Wire Leads - Explosion-Proof with Conduit Connection & Wire Leads
ASHCROFTExplosion-Proof with Conduit Connection & Wire Leads

ASHCROFT Pressure Transmitter: 0 psi to 60 psi, 1 to 5V DC, Cable & Wire Leads

The ASHCROFT A2X Series Explosion-Proof-Rated Transmitter measures gauge pressure from 0 psi to 60 psi with a 1 to 5V DC output and ±0.50% of Full Scale accuracy. It features a stainless steel housing, NPT process…

SKU 3G-OTH-175456

Brand
ASHCROFT
Item
Pressure Transmitter: 0 psi to 60 psi, 1 to 5V DC, Cable & Wire Leads
Category
Explosion-Proof with Conduit Connection & Wire Leads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
A2XBM0215C260#G
Series
A2X
Type
Cable & Wire Leads, IP65 /4X/IP65 /7/IP65 /9
DC
1 to 5V
Output
1 to 5V DC
Accuracy
±0.50% of Full Scale
IP Rating
IP65
NEMA Rating
7
Overpressure
1.5x Range
Product Type
Explosion-Proof-Rated Transmitter
Safety Rating
Class I, Div 1 and 2, Group A, B, C, D
Burst Pressure
2x Range
Housing Material
Stainless Steel
Intrinsically Safe
Not Specified Intrinsically Safe
Pressure Type Measured
Gauge
Process Connection Type
NPT
NIST Traceable Certificate
NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT A2X Series Explosion-Proof-Rated Transmitter measures gauge pressure from 0 psi to 60 psi with a 1 to 5V DC output and ±0.50% of Full Scale accuracy. It features a stainless steel housing, NPT process connection, IP65 and NEMA 7 ratings, and a Safety Rating of Class I, Div 1 and 2, Group A, B, C, D. Overpressure is 1.5x Range and burst pressure is 2x Range. A NIST-Traceable Calibration Certificate is included.

Frequently Asked Questions

What is the ASHCROFT A2X pressure transmitter used for?

The ASHCROFT A2X explosion-proof-rated transmitter measures gauge pressure from 0 psi to 60 psi in hazardous environments. It is used in oil and gas, chemical processing, and industrial applications requiring Class I, Div 1 and 2, Group A, B, C, D safety ratings.

What are the specifications of the ASHCROFT A2XBM0215C260#G?

This ASHCROFT A2X transmitter has a 1 to 5V DC output, ±0.50% of Full Scale accuracy, NPT process connection, stainless steel housing, IP65 and NEMA 7 ratings, overpressure of 1.5x Range, and burst pressure of 2x Range. A NIST-Traceable Calibration Certificate is included.

Where to buy the ASHCROFT A2X pressure transmitter worldwide?

3G Electric supplies and delivers the ASHCROFT A2X pressure transmitter worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this explosion-proof-rated transmitter.

How to install the ASHCROFT A2X explosion-proof transmitter?

Install the ASHCROFT A2X transmitter using the NPT process connection in a conduit system. Ensure the housing is properly sealed to maintain IP65 and NEMA 7 ratings. Follow standard hazardous-area wiring practices for Class I, Div 1 and 2 environments.

Used in

Common applications for ASHCROFT
Process control in chemical plants — ASHCROFT G2 series pressure transmitters with 4-20 mA output
Sanitary monitoring in food processing — ASHCROFT sanitary pressure transmitters with stainless steel fittings
Temperature measurement in oil and gas — ASHCROFT flanged thermowells rated to 1,000°F
Hydraulic system pressure monitoring — ASHCROFT G2 series transmitters with 1-5 V DC output
Hazardous location pressure sensing — ASHCROFT A2X explosion-proof transmitters with conduit connection
Steam system temperature protection — ASHCROFT threaded thermowells rated to 7,000 psi
