ASHCROFT Pressure Transmitter: 0 psi to 5,000 psi, 1 to 5V DC, 4-Pin M12 Connector - Pressure Transmitters with 4-Pin M12 Connector
ASHCROFTPressure Transmitters with 4-Pin M12 Connector

ASHCROFT Pressure Transmitter: 0 psi to 5,000 psi, 1 to 5V DC, 4-Pin M12 Connector

The ASHCROFT G2 Pressure Transmitter (SKU 5LRV6) is a 0 psi to 5,000 psi pressure transmitter with a 4-Pin M12 Connector and a 1 to 5V DC output. It features a nylon housing, a 1/8 in Male NPT process connection, and…

SKU 3G-OTH-176732

Brand
ASHCROFT
Item
Pressure Transmitter: 0 psi to 5,000 psi, 1 to 5V DC, 4-Pin M12 Connector
Category
Pressure Transmitters with 4-Pin M12 Connector
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

ASHCROFT
Manufacturer Part Number
G17M0115EW5000#
Series
G2
Type
IP66 /4X
DC
1 to 5V
Output
1 to 5V DC
Accuracy
±0.5%
Male NPT
1/8 in
IP Rating
IP66
NEMA Rating
4X
Overpressure
1.5x Range
M12 Connector
4-Pin
Burst Pressure
5x Range
Housing Material
Nylon
Process Connection Type
NPT
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

ASHCROFT Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The ASHCROFT G2 Pressure Transmitter (SKU 5LRV6) is a 0 psi to 5,000 psi pressure transmitter with a 4-Pin M12 Connector and a 1 to 5V DC output. It features a nylon housing, a 1/8 in Male NPT process connection, and an accuracy of ±0.5%. The unit is rated IP66 and NEMA 4X, with an overpressure of 1.5x Range and a burst pressure of 5x Range.

Frequently Asked Questions

What is the ASHCROFT G2 pressure transmitter used for?

The ASHCROFT G2 pressure transmitter measures pressure from 0 psi to 5,000 psi in industrial applications such as hydraulics, pneumatics, and process control. Its 1 to 5V DC output and 4-Pin M12 connector simplify integration with PLCs and data acquisition systems.

What are the specifications of the ASHCROFT G2 pressure transmitter?

The ASHCROFT G2 (MPN G17M0115EW5000#) has a range of 0 psi to 5,000 psi, accuracy ±0.5%, output 1 to 5V DC, 4-Pin M12 connector, 1/8 in Male NPT process connection, nylon housing, IP66 and NEMA 4X rating, overpressure 1.5x range, and burst pressure 5x range.

Where to buy the ASHCROFT G2 pressure transmitter worldwide?

3G Electric supplies the ASHCROFT G2 pressure transmitter worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this model.

How to install the ASHCROFT G2 pressure transmitter?

Install the ASHCROFT G2 by threading the 1/8 in Male NPT connection into a compatible port using PTFE tape on the threads. Torque to manufacturer specifications, connect the 4-Pin M12 cable, and apply power (1 to 5V DC output). Avoid over-tightening the nylon housing.

Used in

Common applications for ASHCROFT
Process control in chemical plants — ASHCROFT G2 series pressure transmitters with 4-20 mA output
Sanitary monitoring in food processing — ASHCROFT sanitary pressure transmitters with stainless steel fittings
Temperature measurement in oil and gas — ASHCROFT flanged thermowells rated to 1,000°F
Hydraulic system pressure monitoring — ASHCROFT G2 series transmitters with 1-5 V DC output
Hazardous location pressure sensing — ASHCROFT A2X explosion-proof transmitters with conduit connection
Steam system temperature protection — ASHCROFT threaded thermowells rated to 7,000 psi

ASHCROFT Products

3G Electric supplies ASHCROFT pressure transmitters with 4-pin m12 connector. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
